payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram | Applicable industries: | Advertising Agency, Building Materials Store, Construction Engineering, Energy and Mining, Farm, Food and Beverage Factory, Food and Beverage Store, Grocery Store, Clothing Store, Home Furnishing, Hotel, Machine Repair Shop, Manufacturing Plant, Printing Shop, Restaurant |
port: | Guangzhou, Shenzhen, Zhongshan | Health status: | new |
Warranty: | 3 months | Supply capacity: | 300,000 pieces per day |
product name: | box filter | Frame Material: | Cardboard, galvanized steel, stainless steel |
weight: | 14.2 kg | Filtration level: | High efficiency filter |
Advantage: | widely used filters | Package preview: | |
Origin: | Guangdong, China | media: | Non-woven fabric with pleated mesh support or metal posts |
Core component warranty: | 3 months | Function: | ventilation system, filtration system |
aftersale service provided: | online support | brand: | Creation |
color: | Black | Porosity: | 0.3 microns |
Dimensions (L*W*H): | 595*595*292 | Video outbound inspection: | if |
feature: | environmentally friendly | put up: | box filter |
Packaging Details: | PE bag and carton | Medium material: | activated carbon |
efficiency: | high efficiency | Mechanical test report: | not available |
place of origin; place of origin |
Guangdong, China |
aftersale service provided |
online support |
Warranty |
3 months |
material |
activated carbon |
model |
Pleat 4V_PAP-242412 |
Filtration level |
High efficiency filter |
Applicable industries: |
Hotels, clothing stores, building materials stores, factory, |
Video external inspection: |
not available |
Mechanical test report: |
not available |
Core component warranty: |
3 months |
Core components: |
filter, activated carbon |
Health status: |
new |
efficiency: |
high efficiency |
product name: |
Ahu bag filter |
media: |
Non-woven fabric with pleated mesh support or metal posts |
Frame Material: |
Cardboard, galvanized steel, stainless steel steel plate |
Function: |
ventilation system, filtration system |
temperature |
Continuous working up to 90°C |
Rated air volume: |
800-4200 |
Initial pressure drop: |
80 |
Temperature resistance: |
≤100℃ |
Humidity resistance (relative humidity): |
≤80%RH |
color: |
Black |
feature: |
environmentally friendly |
Advantage: |
widely used filters |
packaging details |
PE bag and carton |
size |
595mm x 595mm x 292mm |
weight |
14.2 kg |
Key words: |
Industrial Filters, Activated Carbon |
model |
PAP-4V-242412-116 |
PBP-4V-242412-116 |
PCP-4V-242412-116 |
Chemical Filter Size |
595x595x292 mm |
595x595x292 mm |
595x595x292mm |
air flow |
3150 |
3150 |
3150 |
initial pressure drop |
75 +/- 15% |
60+/-15% |
<65Pa |
filter medium area |
5.8 |
5.8 |
6.4 |
media type |
ChemSorb Type A |
ChemSorb Type B |
ChemSorb Type C |
target gas |
Molecular acids (H2S, SO2, HF, HCl, HNO3, Cl2..) |
Molecular bases (NH3, amines, NMP..) |
Molecular condensables VOC (Benzene, Toluene, PGMEA, Acetone, MEK..), Ozone, Odor |
initial efficiency |
>90% |
>90% |
>90% |
