Smart 4G GPS Tracker JY-J16A-4G 8-line SOS Mining Truck Oil Cut Off Engine Anti-theft

Supplier: Shanghai Joyroad Technology Co., Ltd.
Region: Shanghai, China
Contact: Mr Lincoln Wilson
Price: $12.00 / 1 - 99 pieces
$10.00 / 100 - 999 pieces
$9.50 / >=1000 pieces
Min. Order: 1 piece

Click here to contact

Product details

Optional features:	reduce fuel	brand:	Avenue of Joy
Packaging Details:	combo	Function one:	track route
Auto Parts:	Cat Track Loaders, Cat Off-Road and Mining	payment terms:	L/C, Western Union, T/T, MoneyGram, PayPal
Year:	1994-1996,1981-1982,1994-2000,1982-1996,1997-2000,1980,1985-1996,1978-1979,1979-1993	port:	Shanghai
frequency band:	B1/B3/B5/B8/B34/B38/B39/B40/B41	Product Features:	Cut off the engine
Voltage:	9-120V	Package preview:
OBD bus:	support	playback:	route replay
Suitable:	Car Sharing Car Control	Function:	Protect Your Vehicle Assets
Supply capacity:	100000 boxes per month	Warranty:	12 months
Function 2:	call for help	waterproof:	IP69K
application:	remote management	Model:	983B, 785B, 769C, 777D
Chip type:	A7670C-MASS	2/3/4G and GPS Antenna:	External

Specifications	Specification
size	803917mm
weight	49.1g (including battery)
Built-in battery	150mAh (3.7V)
Operating temperature	-20°C to +60°C
Storage temperature	-20°C to +70°C
sensor	Precision Vibration Sensor
band	LTE-FDD: B1/B3/B5/B8 Time division drive: B34/B38/B39/B40/B41
Communication module brand/chip model	A7670C-MASS
Positioning module brand/chip model	A7670C-MASS
root mean square error	S degree
Maximum output power	EGSM900: 33dBm±2dB/5dBm±5dB DCS1800: 30dBm±2dB/0dBm±5dB EGSM900 (8-PSK): 27dBm±3dB/5dBm±5dB DCS1800 (8-PSK): 26dBm±3dB/0dBm±5dB WCDMA B1/B5/B8: 24dBm+1/-3dB/<-49dBm LTE-FDD B1/B3/B5/B8: 23dBm±2dB/<-39dBm LTE-TDD B34/B38/B39/B40/B41: 23dBm±2dB/<-39dBm
Dynamic output range	-15~-108dbm
Receiver sensitivity	-107dbm
maximum frequency error	±0.1ppm
sensitivity	Cold start: -145dbm Hot start: -156dbm Hot start: -145dbm Navigation: -160 dB Trace: -162dbm
time to first fix	Cold start: average 32 seconds
GSM antenna	built
GPS antenna	built
LED indicator	Power, status indication
Transfer Protocol	transmission control protocol
power detection	Upload alarm information when the main power is disconnected
data report	GPS data real-time update, support customer customization
electric fence	to be determined
Driving Behavior Detection	The vehicle speed exceeds the set speed and an overspeed alarm is uploaded
GPS data	Live Location Updates
vibration alarm	Report Vehicle Vibration in Enhanced State

content		Function	clarify
GPS	4G full Netcom		Support 4G network, efficient transmission within 1 second, faster and more accurate.
	timing tracking		Returns location information such as latitude and longitude according to the set interval.
	street view map		360-degree high-definition map, no dead ends
	Overspeed alarm		Locator sends an alert to your phone when driving over the speed limit
	vibration alarm		Built-in vibration sensor, the vehicle vibrates continuously, and the device immediately sends out an alarm prompt
	electric fence		If the vehicle travels beyond the designated area, an alarm message will be sent to the platform
	Historical track		Can play back 365 days of driving track, playback current speed, direction dwell time, etc.
	Displacement alarm		When the vehicle encounters illegal operation or is stolen, the oil and power can be cut off remotely through the computer or mobile APP
	fleet management		1 mobile phone can manage multiple devices, or 1 device can manage multiple mobile phones

symptom	Failure Analysis	processing method
blue light blinking slowly	Determine whether to use the terminal in areas with poor GPS signals, such as near tall buildings, underground parking lots, etc.	Use the terminal to drive the vehicle to a location with good signal
	Determine whether the front windshield of the vehicle has a metal insulating film that affects signal reception	If there is a film, replace the device to another vehicle to test whether the blue light is always on. If there is no problem in the test on other vehicles without film, it is caused by the vehicle film
	Determine if there are shields or signal jammers on or around the car	If there is a shield or source of interference, remove the shield or source and try reinstalling
Blue light flashes quickly	chip failure	Return to factory for repair
yellow light flashes quickly	Determine whether the SIM card is installed	Check if the SIM card is installed in place
yellow light flashes quickly	Determine whether the metal surface of the SIM card is dirty or in poor contact	Wipe the surface of the metal chip with a clean cloth or insert and remove the card multiple times
slow flashing yellow light	Determine whether the vehicle is in a place without a mobile network, such as an underground parking lot	Please drive the vehicle to a place with a good network signal and try to reinstall
	Determine whether the server background is normal	Ask whether the background management platform server is normal
	Determine whether the status of the SIM card is normal	Check whether the status of the card is normal through the SIM card query platform
	Determine if there are shields or signal jammers on or around the car	If there is a shield or source of interference, try removing the shield or source of interference again
