Falcon fixed installation series-horizontal winch (can be customized) Lighting design/nightclub/theater/bar

Supplier: Jinan Chaokong Electrical Equipment Co., Ltd.
Region: Shandong, China
Contact: Ms wu sufang
Price: $5999.00 / 1 - 4 sets
$599.00 / >=5 sets
Min. Order: 1 set

Click here to contact

Product details

weight:	353-620kg	model:	W400 W600 W800 W1000 W1200
Customization support:	OEM, ODM, OBM	Dimensions lengthwidthheight:	(1316-2098)×355×1215/(1333-2653)×392×1336 mm
brake:	Double brake	brand:	Jinan Chaokong Electrical Equipment Co., Ltd.
Energy source:	electrical	Maximum stroke:	15-30m
Packaging details:	Standard packaging (wooden box or flight case)	application:	crane
Supply capacity:	30 sets per month	Warranty:	12 months
strength:	1.1-7.5 1.5-11 2.2-15 3-18.5 3-22kw,710W,1400W,1200W	Package preview:
Voltage:	24VDC/220VAC/380VAC/440VAC	load:	400-1200kg
Place of origin:	Shandong Province, China	Wire rope diameter:	6mm
payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram	speed:	0.2-1.5 meters/second
Lifting point:	3-8 pieces	port:	Qingdao Port

Multiple hanging points for stage machinery and equipment

Fixed installation series-horizontal winch

Stage lifts are mainly suitable for fixed installation in the field of commercial stage construction and are used for stage
Architecture/mobile performances, stage sets, sound and lighting arrangements. Single machine control or multi-machine linkage
Designed to meet your needs for a variety of operations, this new hoist is more
It has features suitable for different purposes and has extensive customization capabilities. It is ready for various uses.

Mechanical components It consists of motor, reducer, encoder, stroke detection, wire rope drum, flange, random rope detection, wire rope drum vertical plate, etc.
Features1. Stable structure, safe and reliable. 2. Integrate orbital rope winding technology to solve the problems of rope skipping and rope tangles. 3. Easy to install. 4. Suitable for large and medium-sized theaters, multi-functional halls, lecture halls, etc.

Model	W400 W600 W800 W1000 W1200
Speed (m/s)	0.2-1.5
Load (kg)	400-1200
Power (kW)	1.1-7.5 1.5-11 2.2-15 3-18.5 3-22
Lifting point(Pc)	3-8
Maximum stroke(m)	15-30 days
Wire rope diameter (mm)	6
brake	Double brake
Dimensions (length x width x height) (mm)	(1316-2098)×355×1215/ (1333-2653)×392×1336
Weight (kg)	353-620

Safe and reliable

High safety factor: All components between the load and the brake are always designed to exceed the rated load. The precise walking control technology is equipped with dual encoders to meet the requirements of uniform speed and lifting. Winches are always equipped with two independent brakes, each capable of safely stopping the load, thus preventing unintentional dangerous movement. Low Maintenance - All winches are designed for a long operating life at full load and speed, ensuring low maintenance, reliability and no need for replacement. Suitable for stand-alone and integrated control systems.

security function

High safety factor: All components between the load and the brake are always designed to exceed the rated load.
The precise walking control technology is equipped with dual encoders to meet the requirements of uniform speed and lifting.
Winches are always equipped with two independent brakes, each capable of safely stopping the load, thus preventing unexpected hazards
action.
Low Maintenance - All winches are designed for a long working life at full load and speed, ensuring low maintenance,
Reliable and no replacement required.
Suitable for stand-alone and integrated control systems.
The wire ropes are stacked on the rails in an orderly manner, and the sensing device prevents the ropes from loosening and the ropes from folding.

1. What information do I need to provide when making an inquiry? More details or drawings, the more the better. A: Lifting capacity B: Span C: Lifting height D: Power source or other special offers you give us will be more appreciated. 2. Can you provide lifting tools? Of course, we can provide any lifting tools according to your requirements, such as lifting slings, lifting clamps, grabs, magnets or other specials! 3. How to install the crane? Our senior engineers can provide installation guidance services and training by your side. Furthermore, our best sales can visit your country.

Jinan Chaokong Electrical Equipment Co., Ltd.It is a new cultural technology cross-border company. It mainly provides non-standard mechanical design, production and non-standard automation control comprehensive solutions for various theaters, performance venues and large-scale performance special devices, special equipment and control system engineering projects. The company is committed to the integration and innovation of culture and technology, and provides solutions and implementation services integrating R&D, equipment system integration, and operation management for key technical equipment in cultural tourism, performing arts, art exhibitions and other fields.
