fuel: | diesel engine | Transmission type: | manual |
payment terms: | Letter of credit, wire transfer | Dimensions: | 5780*2000*2760mm |
Cabin dimensions: | 3220*1750*1840mm | Power horsepower (hp): | 103 |
Shift: | 2198ml | engine model: | DURATORQ4D226H |
color: | white+red | brand: | Yuzhou brand |
Gasoline type: | diesel engine | Supply capacity: | 600 units per year |
Driver type: | 4X2 left-hand drive vehicle | Chassis brand: | Jiangling Ford |
Medical equipment: | Yes | port: | Zhuhai Port/Guangzhou Port/Shenzhen Port |
Length (meters): | 3-8m | Package preview: | |
Total weight: | 3700kg | Place of origin: | Guangdong, China |
Emission Standards: | Euro 6 | Health status: | new |
basic data | ||
Model | GPY5041XJHSHTT0 | |
Engine type | SC25R136.1Q5 | |
Gasoline type | diesel engine | |
Displacement (ml) | 2499 | |
Emission Standards | Euro 5 | |
Curb weight (kg) | 2800 | |
Gross vehicle weight (kg) | 3800 | |
Wheelbase (mm) | 3850 | |
How the engine works | In-line 4-cylinder, water-cooled direct injection, intercooling, direct injection, compression ignition | |
Vehicle size (mm) | 5700×1998×2740mm (length×width×height) | |
Maximum power (Kw/rpm) | 100/3800 | |
Maximum torque Nm/rpm | 330/1800-2400 | |
suspension system | Front: MacPherson independent suspension Rear: leaf spring non-independent suspension | |
Braking System | Disc brakes on all wheels | |
spread | 6 tons | |
Top speed (km/h) | 150 | |
Fuel tank capacity (L) | 80 | |
seat | 3-9 |
medical compartment device | ||||
1. | There is a partition wall between the cab and the medical room, which separates the front and rear compartments. Partition wall with visible windows. | 1 | ||
2. | Installation of composite Walker flame retardant panel equipment cabinets. | 1 | ||
3. | Install composite Walker flame retardant board medical device integrated cabinet. | 1 | ||
4. | A composite Walker flame retardant board medicine cabinet is installed on the left side of the partition wall. | 1 | ||
5. | Install folding doctor chairs on the partition wall of the medical cabin | 1 | ||
6. | The first aid box fixed cabinet is installed on the right side of the medical cabin partition wall. | 1 | ||
7. | Install the upper pedal on the middle door of the medical compartment. | 1 | ||
8. | The middle door of the medical cabin is equipped with all-round safety handrails. | 1 | ||
9. | A long row of 3-person cabinet seats is installed on the right side of the medical cabin. | 1 | ||
10. | Install oxygen stationary cabinet. | 1 | ||
11. | 10 liter oxygen cylinder (with pressure reducing valve). | 1 | ||
12. | Install an oxygen humidifier. | 1 | ||
13. | Install onboard oxygen terminals (for ventilators and humidifiers). | 1 | ||
14. | Equipment rack installation. | 1 | ||
15. | Install top safety rails. | 1 | ||
16. | Install a two-way ventilation fan. | 1 | ||
17. | Install 2 bottles of infusion box | 2 | ||
18. | Install 8 medical long lockers. | 1 | ||
19. | Install a 1kg fire extinguisher and support frame. | 1 | ||
20. | Install insulation and soundproofing layers. | 1 | ||
twenty one. | The floor of the medical cabin is made of acid and alkali resistant, fireproof, anti-skid and anti-static floor leather. | 1 | ||
twenty two. | Install a set of anti-collision soft bags. | 1 | ||
twenty three. | Install front and rear intercom systems. | 1 | ||
twenty four. | Emergency reset car stretcher and platform (with fixator and safety belt) | 1 | ||
25. | Standard negative pressure filtration system installation | 1 |
