Vehicle parameters | ||||||
General | Vehicle model | YZR5170GXFSG70 | ||||
vehicle brand | XDR | |||||
Chassis brand | ISUZU(QL1160VMFRY) | |||||
Overall dimensions (mm) | 8080×2500×3470 | |||||
GVW/curb weight (kg) | 16800/9750/6600 | |||||
Chassis parameters | ||||||
taxi | Cab seat | 2+4 | ||||
air conditioner | Yes | |||||
engine | Fuel type | diesel engine | ||||
engine model | 4HK1-TC50 | |||||
Engine brand | Isuzu | |||||
Power (kW/horsepower) | 151/205 | |||||
Displacement(cc) | 5193 | |||||
Emission standards | Euro 5 | |||||
chassis | Drive type | 4*2 | ||||
spread | 6 speed, manual | |||||
Wheelbase (mm) | 4500 | |||||
Tire specifications | 1000R20 | |||||
Number of tires (strips) | 6+1 | |||||
Maximum speed (km/h) | 90 | |||||
painting | red | |||||
Fire truck water tank structural parameters | ||||||
Tank volume | 6000L | Tank material | carbon steel | |||
Tank thickness | 4/3/3mm | fire pump | CB10/40 | |||
fire cannon | PS40 | color | red | |||
Standard configuration | Chassis, subframe, cabin, national standard equipment box, 25 sets of national standard fire fighting equipment, fire pump (CB10/40 According to capacity), fire gun (PS40 according to capacity), fire power take-off, sliding door, row light, reel, Common tools, rear ladder, water tank. |
fire extinguishing equipment | 1 | Suction tube | Φ100×2m | 4 | piece | Thread |
2 | water filter | FLF100 | 1 | piece | Thread type | |
3 | manifold | FII80/65×2-1.6 | 1 | piece | Internal buckle type | |
4 | collector | JII100/65×2-1.0 | 1 | piece | Internal buckle type | |
5 | water pipe | 13/65/20 | 6 | roll | Low pressure: internal buckle type | |
6 | water pipe | 13/80/20 | 2 | roll | Low pressure: internal buckle type | |
7 | water pipe | 13-65-5 | 1 | roll | Low pressure: internal buckle type | |
8 | Reduction joint | KJ65/80 | 1 | piece | Buckle type | |
9 | Water pipe packaging | DT-SB | 4 | piece | ||
10 | Watch strap protective cover | Length: 570 | 2 | a pair | ||
11 | water pipe hook | 4 | piece | |||
12 | Rear fire hydrant wrench | QT-DS1; length: 400 | 1 | piece | ||
13 | Flush hydrant wrench | Length: 860 | 1 | piece | ||
14 | straw wrench | FS100 | 2 | piece | ||
15 | DC nozzle | QZG3.5/7.5;65 | 1 | piece | Low pressure: internal buckle type | |
16 | DC nozzle | QZK3.5/7.5;65 | 1 | piece | Low pressure: internal buckle type | |
No. 17 | Air foam gun (with tube) | QP4/0.7Z;65 | 1 | piece | Only suitable for foam fire trucks | |
18 | Foam outer straw assembly | Φ40×2700 | 1 | piece | Only suitable for foam fire trucks | |
Forced entry rescue tool | 1 | fire extinguisher | 3kg/ABC | 1 | piece | |
2 | shovel | Length: 1050 | 1 | piece | ||
3 | ax | Length: 390; GF-285 | 1 | piece | ||
4 | T-shaped pick | QTF-DG; length: 830 | 1 | piece | ||
5 | crowbar | Length: 1060 | 1 | piece | ||
6 | flat ax | QTF-PF; long 810 | 1 | piece | ||
7 | Rubber hammer | 1 | piece |
