Structure: | pilot operated diaphragm; | temperature: | medium; |
Packaging Detail: | CTN size: 21*31*25cm then into one pallet; | Port Size: | 3/4''-3'; |
Standard or Nonstandard: | Standard; | Guarantee: | one and half year; |
Pressure: | High Pressure; | Material: | nylon; |
Port: | ningbo/shanghai,china; | Brand Name: | YONGCHUANG; |
Port size: | 3/4'-3'; | Media: | water; |
Model Number: | YCA11/21; | Power: | Solenoid; |
Place of origin: | ningbo,china; | Structure: | pilot operated diaphragm; |
Application: | lawn irrigation system; | Pressure: | max 10 bar; |
Supply Ability: | 20000 Piece/Pieces per Month; | Coil: | energy saving,low maintanance power; |
Application: | lawn irrigation,gym,agriculture,water treatment; | Working mode: | latching,energy saving; |
Place of Origin: | Zhejiang China; | Payment Terms: | L/C,T/T,Western Union; |
Temperature of Media: | Medium Temperature; |
Characteristic | 1)Pilot operated diaphragm structure,hight strength nylon body 2)Double filtration anti blocking solenoid core 3)Full colsed coil water proof 4)close slowly,anti water hammer |
Medium | water |
Temperature | NBR seal:-10°C to 80 °C |
Pressure | 0.01-1.0Mpa |
Port size | 3/4'-2' |
Port thread | G,NPT |
Orifice | 20-80mm |
Voltage | DC-12V,24V AC-24V,120V,110V,220V/50HZ |
Tolerance | ±10% |
Coil | L32B,DC6-20V,pulse length(20-500Ms) |
Special coils | |
Material | Body-nylon Seal- NBR Amature tube-stainless steel 304 Plunger-stainless steel430F Stop-stainless steel 430F Springs-SS304 Shading rings- stainless steel 304 |
|
