Package: | Original Koyo Packing; | Product name: | bearing 6205; |
Structure: | Deep Groove; | Type: | Ball; |
Noise Level: | EMQ V1 Z2 EMQ V2 Z3 EMQ V3 Z4; | Material: | Chrome steel,Stainless steel; |
Sample: | available; | Weight: | 0.128kg/pc; |
Packaging Detail: | KOYO brand package for bearing 6205; | Supply Ability: | 100000 Set/Sets per Month bearing 6205; |
Cage: | steel Cage ,Brass cage,Nylon Cage; | Bore Size: | 24.99 - 25 mm; |
Port: | GUANGZHOU,SHENZHEN,SHANGHAI; | Model Number: | bearing 6205; |
Place of Origin: | Japan; | Outside Diameter: | 51.99 - 52 mm; |
Vibration level codes: | V4, V3, V2, V1; | Number of Row: | Single Row; |
Size: | 25*52*15mm; | Brand Name: | Koyo; |
Width: | 15mm; | Seals Type: | OPEN ZZ RS; |
Precision Rating: | P0 P6 P5 P4 P2; | Payment Terms: | L/C,T/T,Western Union,Paypal; |
Koyo Bearings in Japan 6205 Deep Groove Ball Bearing
New code | Koyo Bearing 6205 2RS |
---|---|
Bearing type | Deep groove ball bearings |
Brand | KOYO |
Business type | Japan Koyo bearings Distributor |
Id (mm) | 25 |
OD (mm) | 52 |
B (mm) | 15 |
Cr(kN) | 14.0 |
Cor(kN) | 7.85 |
Speed for grease lubrication (r/min) | 13000 |
Oil lubrication speed (r/min) | 15000 |
Weight(kg) | 0.128 |
Material | Chrome steel or Stainless steel |
Delivery time | 2-5 days of stock, 15-50 days for OEM |
Packing | Standard Koyo bearing package |
Payment terms | T/T, Western Union, Paypal |
Gurantee | 2 years |
KOYO 6200 series bearing catalogue:
Bearing NO. | Old NO. | ID | OD | B | Cr | Cor | Max Speed (Grease) | Max Speed (Oil) | Mass |
(mm) | (mm) | (mm) | (kN) | (kN) | (r/min) | (r/min) | (kg) |
6200 | 200 | 10 | 30 | 9 | 5.1 | 2.38 | 20000 | 26000 | 0.032 |
6201 | 201 | 12 | 32 | 10 | 6.82 | 3.05 | 19000 | 24000 | 0.037 |
6202 | 202 | 15 | 35 | 11 | 7.65 | 3.72 | 18000 | 22000 | 0.045 |
6203 | 203 | 17 | 40 | 12 | 9.58 | 4.78 | 16000 | 20000 | 0.065 |
6204 | 204 | 20 | 47 | 14 | 12.8 | 6.65 | 14000 | 18000 | 0.106 |
6205 | 205 | 25 | 52 | 15 | 14 | 7.85 | 13000 | 15000 | 0.128 |
6206 | 206 | 30 | 62 | 16 | 19.5 | 11.3 | 11000 | 13000 | 0.199 |
6207 | 207 | 35 | 72 | 17 | 25.7 | 15.4 | 9200 | 11000 | 0.288 |
6208 | 208 | 40 | 80 | 18 | 29.5 | 18 | 8000 | 10000 | 0.368 |
6209 | 209 | 45 | 85 | 19 | 31.5 | 20.5 | 7000 | 9000 | 0.416 |
6210 | 210 | 50 | 90 | 20 | 35 | 23.2 | 6700 | 8500 | 0.463 |
6211 | 211 | 55 | 100 | 21 | 43.2 | 29.2 | 6000 | 7500 | 0.603 |
6212 | 212 | 60 | 110 | 22 | 47.8 | 32.8 | 5600 | 7000 | 0.789 |
6213 | 213 | 60 | 120 | 23 | 57.2 | 40 | 5000 | 6300 | 0.99 |
6214 | 214 | 70 | 125 | 24 | 60.8 | 45 | 4800 | 6000 | 1.084 |
6215 | 215 | 75 | 130 | 25 | 66 | 49.5 | 4500 | 5600 | 1.171 |
6216 | 216 | 80 | 140 | 26 | 71.5 | 54.2 | 4300 | 5300 | 1.448 |
6217 | 217 | 85 | 150 | 28 | 83.2 | 63.8 | 4000 | 5000 | 1.803 |
6218 | 218 | 90 | 160 | 30 | 95.8 | 71.5 | 3800 | 4800 | 2.17 |
6219 | 219 | 95 | 170 | 32 | 110 | 82.8 | 3600 | 4500 | 2.62 |
6220 | 220 | 100 | 180 | 34 | 122 | 92.8 | 3400 | 4300 | 3.19 |
6221 | 221 | 105 | 190 | 36 | 133 | 105 | 3200 | 4000 | 3.78 |
6222 | 222 | 110 | 200 | 38 | 144 | 117 | 3000 | 3800 | 4.42 |
6224 | 224 | 120 | 215 | 40 | 155 | 131 | 2600 | 3400 | 5.3 |
6226 | 226 | 130 | 230 | 40 | 165 | 148 | 2400 | 3200 | 6.12 |
6228 | 228 | 140 | 250 | 42 | 179 | 167 | 2000 | 2800 | 7.77 |
6230 | 230 | 150 | 270 | 45 | 203 | 199 | 1900 | 2600 | 9.78 |
6232 | 232 | 160 | 290 | 48 | 215 | 218 | 1800 | 2400 | 12.22 |
6234 | 234 | 170 | 310 | 52 | 245 | 260 | 1700 | 2200 | 15.241 |
6236 | 236 | 180 | 320 | 52 | 262 | 285 | 1600 | 2000 | 15.518 |
6238 | 238 | 190 | 340 | 55 | 285 | 322 | 1500 | 1900 | 18.691 |
6240 | 240 | 200 | 360 | 58 | 288 | 332 | 1400 | 1800 | 22.577 |
6244 | 244 | 220 | 400 | 65 | 355 | 365 | 1200 | 1600 | 36.5 |
6248 | 248 | 240 | 440 | 72 | 358 | 467 | 1000 | 1400 | 53.9 |
Jinan Kelunte Bearing Co., Ltd. is a professional bearing manufacturer and is engaged in the imported bearings. Our company is engaged in the imported bearings,company's main imported Roller Bearing,Ball Bearing,deep groove ball bearings,taper roller bearings,angular contact ball bearings,Pillow Block Bearing,Ceramic Bearing,cylindrical roller bearing, spherical roller bearing . and our brands:CLUNT.
