Outdoor indoor vertical wheelchair platform lift for disabled

Supplier: Jinan Sinicmech Machinery Co., Ltd.
Region: Shandong, China
Contact: Mr Ryan GUO
Price: $3880.00 /set
Min. Order: 1 set

Click here to contact

Product details

Certification:	CE;	Overall Dimensions:	143015004050mm;
Safety device:	Down platform safety sensor;	Applicable Industries:	Hotels,Garment Shops,Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Food & Beverage Factory,Farms,Restaurant,Home Use,Retail,Food Shop,Printing Shops,Construction works ,Energy & Mining,Food & Beverage Shops,Advertising Company;
Control mode:	calling box and remote control;	Lift Mechanism:	Lift Chain;
Place of Origin:	Shandong China;	Supply Ability:	200 Set/Sets per Year;
Brand Name:	MORN LIFT;	Interlock:	yes;
Table Size:	1400*900mm;	Min. Lifting Height:	60mm;
Control mode 2:	Post switch;	Lift speed:	60mm/s;
Installation:	Easy install no pit;	Power:	1.5kw;
After-sales Service Provided:	Engineers available to service machinery overseas;	Emergency Stop:	Manual emergency stop valve;
After-sales Service Provided:	Free spare parts;	Lift Drive / Actuation:	Hydraulic;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal;	Packaging Detail:	Veneer case for one unit wheelchair lift Packing size: 23001600500mm;
Weight:	500kg;	Port:	Qingdao, Shanghai, Tianjin, Ningbo;
Material Option:	Stainless steel;	Warranty:	1 Year;
Materials:	Aluminum alloy;

Outdoor indoor vertical wheelchair platform lift for disabled

Product Description

Light Weight. Aluminium alloymetarial.
Easy Operation: button press.
Emergency stop switch on platform.
Quite, smooth ride.

Safety Sensor

Home elevator lift stop running if bottom meet obstacle to protect people under platform.

Electrical Interlock

Home elevator stop lifting up or down when door is not closed.

Manual Down

Pull out the switch to enable home elevator fall down safely when when power cut suddenly.

Packaging & Shipping

1. Film package to prevent humidity and rust.
2. Iron frame to keep lift stable in container.
3. Plywood to prevent vertical platform lift from colliding. Convenient for forklift delivery.

4 Packing size: 2300*1600*500mm

Options

Cabin type small home elevator

Recommended for all unenclosed applications.

Full caged

Rain proof

Landing gate

Including control button and emergency stop buttong.

Model List

Model	Lifting height	Load capacity	Platform size	Self weight	Manual Door
WL-1	1000mm	250kg	1430*900mm	350kg	Yes
WL-2	2000mm	250kg	1430*900mm	550kg	Yes
WL-3	3000mm	250kg	1430*900mm	780kg	Yes
WL-4	4000mm	250kg	1430*900mm	880kg	Yes
WL-5	5000mm	250kg	1430*900mm	1000kg	Yes
WL-6	6000MM	250kg	1430*900mm	1100kg	Yes

MORN electric vertical platform lift can be installed both indoor and outdoor.

Easy installed by expansion screw on ground and walls.

Company Information

Manufacturing technology & process

1. MORN production process is controlled by strict Inner Quality Control System.

2. Apply to CE standard.

3. Full set of CNC manufacturing equipment, standard production lines and fast delivery with sufficient stocks.

Warranty and service

1. Warranty: 12 months apart from man-made faults from receiving the lift, if the installation
is delayed for some reason, the warranty can be delayed to max 18 months.

2. The spare parts can be provided for free during the warranty.

3. During the warranty, if the equipment was broken due to the quality itself, we can do the free
maintenance and provide the needed spare parts until it can work for normal use. If it is
man-made faults, you need pay the material cost.

4. Tires, electric parts do not belong to the scope of warranty.

5. We provide all-life long technical support, online and telephone service.
