Certification: | ISO9001; | Engine: | 4TNV98T-ZNLYS; |
Single gross weight: | 1,045 KG; | Moving Type: | Wheel Loader; |
Emission Standard: | EPA Tier3 & EU Stage IIIA; | UNIQUE SELLING POINT: | High operating efficiency; |
Single package size: | 354X183X202 cm; | Dump Reach @ Full Height: | 587 mm; |
Type: | Skid Steer Loader; | Power(W): | 61.3kw; |
Gross Power: | 61.3kw@2400rpm; | Tire Size: | 14-17.5; |
Warranty: | 1 Year; | Package Preview: | https://sc01.alicdn.com/kf/HTB1GCzNaUz1gK0jSZLeq6z9kVXa5.jpg_640x640.jpg; |
Hydraulic Pump Brand: | Imported; | Selling Units: | Single item; |
Dump Clearance @ Full Height: | 2572 mm; | Operating Weight: | 3750 kg; |
Number of Cylinder: | 4; | Package Type: | nude packing or by container; |
Condition: | New; | Place of Origin: | Jiangsu China; |
After-sales Service Provided: | Engineers available to service machinery overseas; | Applicable Industries: | Hotels,Garment Shops,Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Food & Beverage Factory,Farms,Restaurant,Home Use,Retail,Food Shop,Printing Shops,Construction works ,Energy & Mining,Food & Beverage Shops,Advertising Company; |
Hydraulic Cylinder Brand: | Imported; | Engine Brand: | Imported; |
Dimension(Long * Breadth * High): | 2973*1850*2034mm; | Wheel base: | 1334 mm; |
Brand Name: | Liugong; | Machine Weight: | 3750 KG; |
Bucket capacity: | 0.45cbm; | Hydraulic Valve Brand: | Imported; |
After-sales Service Provided: | Field installation, commissioning and training,Field maintenance and repair service,Video technical support,Online support,Free spare parts; |
Main Characteristics
Built for Efficiency
The self-leveling valve maintains an even level and keeps the highly stable design more balanced, this leveling also prevents bucket spillage bucket making work more efficient.Larger capacity 105 L fuel tank for longer working hours.The 385B is the ultimate in utility with a easy to use quick coupler for working with LiuGong’s wide range of quality attachments, in addition to being compatible with attachments from other suppliers.
Easy to Maintain
When the engine hood open plenty of space for maintenance is available and parts are easy to access.A suction cooling system is usedfor powerful cooling.The hydraulic pipes and electrical circuits are laid out to be easy to maintain and provide adequate space for inspection and maintenance.The cab tilts back to over 80 degrees, giving ample space to replace the engine oil filter, hydraulic oil filter, and more.Convenient for daily checking and servicing of the hydraulic system.Centralized placement of resistance boxes and relay of electrical system makes it easy to inspect and maintain.Filler port and viewport of chain box are designed for convenient maintenance.
Always Reliable
The drive hydraulic system is a closed hydraulic system with a REXROTH double piston pump and a POCLAIN motor.The compact closed hydraulic system reduces leaks , lowers hydraulic shocks , and is highly reliable.Standard hydraulic parking brake offers reliable and stable braking.A reliable TYC transmission chain.The working hydraulic system is a open system with a Permco gear pump and a WALVOIL triple pilot control valve.The hydraulic system in the 365B is fully equipped with 24 degree tapered seals with O-rings on hose connections to provide the best seals possible and give operators peace of mind.Mono-block frame has good stability and high strength.Box frame for boom with high strength, low weight and extreme durability.
Operator Comfort and Safety
Safety :ROPS/FOPS cab.2 inch Seat belt and safety handrail.Optional fire extinguisher.Safety sensors on front door.Comfort:Adjustable seat with shock absorption.Optional high-grade seat.Easy-Pull, Easy-Secure side windows.Optional radio with MP3.Ergonomic low-effort pilot joysticks reduce operator’s fatigue. The switches on the joysticks control the auxiliary hydraulic kit for finger control.Optional heater and air conditioner for operator comfort.Centralized monitoring instruments (left) and working buttons (right).Hand accelerator on the right side offers fixed power output, which reduces the operator’s fatigue.Standard boom bumper prevents the boom from falling.Standard back-up alarm.Optional rotary beacon.Standard cigarette lighter/electrical outlet.
Engine | |||
Emission Standard | EPA Tier3 & EU Stage IIIA | EPA Tier3 & EU Stage IIIA | |
Model | 4TNV98T-ZNLYS | 1104D-44T | |
Gross Power | kW(hp)@rpm | 61.3(82.5)@2400 | 62.5(82.5)@2400 |
Net Power | kW(hp)@rpm | 57.3(76.8)@2400 | / |
Number of Cylinder | 4 | 4 | |
Torque Raise | 20% | 20% | |
Peak Torque | N.m@rpm | 292.6@1550 | 354@1400 |
Displacement | L | 3.3 | 4.4 |
Working Hydraulic System | |||
System Type | open | open | |
Standard Fow | L/min | 79.2 | 79.2 |
optional High Fow | L/min | 120.2 | 120.2 |
Working Hydrostatic Pressure | Mpa | 21 | 21 |
Hydraulic Cycle Time, total | second | 8.27 | 8.27 |
Raise | second | 3.66 | 3.66 |
Dump | second | 2.82 | 2.82 |
Lower(empty, foat down) | second | 1.79 | 1.79 |
Travellling Hydraulic System | |||
System Type | Closed | Closed | |
Traveling Hydrostatic Pressure | L/min | 35 | 35 |
Drive Chain Size | 100HS | 100HS | |
Max Travel speed | km/h | 11.6 | 11.6 |
Max Travel Speed with optional 2 | km/h | 23.1 | 23.1 |
Tires | |||
–Standard Tire | |||
Ply Type | Vacuum tyre | Vacuum tyre | |
Tire Size | 12-16.5 TI200 | 12-16.5 TI200 | |
Ply Rating | 12 | 12 | |
–Option 1 | |||
Ply Type | Vacuum tyre | Vacuum tyre | |
Tire Size | 14-17.5 | 14-17.5 | |
Ply Rating | 14 | 14 | |
–Option 2 | |||
Ply Type | solid tyre | solid tyre | |
Tire Size | 33x12x20 | 33x12x20 | |
Ply Rating | / | / | |
Weight | |||
Operating Weight | kg | 3750 | 3750 |
optional Counterweight | kg | 160 | 160 |
Loader | |||
Tipping LLoad | kg | 2090 | 2090 |
Rated Operation Capacity | kg | 1045(2300) | 1045(2300) |
Rated Operation Capacity with Counterweight | kg | 1111(2450) | 1111(2450) |
Boom Breakout Force | kN | 20.31 | 20.31 |
Bucket Breakout Force | kN | 29.81 | 29.81 |
Dimension | |||
Bucket Rollback @ Ground Level | degree | 30 | 30 |
Maximum Dump Angle @ Full Height | degree | 39 | 39 |
Dump Clearance @ Full Height | mm | 2572 | 2572 |
Dump Reach @ Full Height | mm | 587 | 587 |
Maximum Hinge Pin Height | mm | 3278 | 3278 |
Maximum Working Height @ Full Height | mm | 4176 | 4176 |
Maximum Rollback Angle @ Full Height | degree | 99 | 99 |
Ground Clearance | mm | 200 | 200 |
Wheel tread | mm | 1536 | 1536 |
Wheel base | mm | 1334 | 1334 |
Angle of Departure | degree | 27 | 27 |
Overall Length with Standard Bucket | mm | 3851 | 3851 |
Overall Length without Standard Bucket | mm | 2973 | 2973 |
Overall Width with Standard Bucket | mm | 1850 | 1850 |
Overall Width without Standard Bucket | mm | 1850 | 1850 |
Overall Height to top of Cab | mm | 2034 | 2034 |
Front Clearance Radius with bucket | mm | 2324 | 2324 |
Front Clearance Radius without bucket | mm | 1414 | 1414 |
Electrical System | |||
System Voltage | V | 12 | 12 |
Alternator Output | amps | 85 | 85 |
Service Capacities | |||
Fuel Tank | L | 110 | 110 |
Engine Oil | L | 9 | 9 |
Cooling System | L | 20 | 20 |
