LAN Ports: | 4; | RAM: | 128MB; |
Application: | HOME; | Maximum Connected Users: | 32; |
Main Chip: | MDM9207; | Certification: | CE ROHS FCC; |
Standards And Protocols: | Wi-Fi 802.11b,Wi-Fi 802.11g,Wi-Fi 802.11n; | Payment Terms: | L/C,D/A,T/T; |
Packaging Detail: | Standard; | Type: | Wireless; |
Wi-Fi Transmission Standard: | 802.11n; | Port: | SHENZHEN PORT; |
Supply Ability: | 10000 Piece/Pieces per Month; | WAN Ports: | 1; |
Max. LAN Data Rate: | 150Mbps; | 2.4G Wi-Fi Transmission Rate: | 300 Mbps; |
Wired Transfer Rate: | 150 Mbps; | Products Status: | Stock; |
Interface: | 3LAN/1WAN; | Brand Name: | OEM; |
Function: | Firewall,VPN; | Wireless Security: | 64/128-bit WEP/WPA-PSK/WPA2-PSK/TKIP/AES; |
VPN Support: | IPSec /PPTP /L2TPPass-through; IPSec VPN; | sim card: | support; |
With Modem Function: | Yes; | Wi-Fi Supported Frequency: | 2.4G; |
Power: | 12V DC/1A or 5V DC/1A; | Dimensions: | 190*134*31mm; |
Place of Origin: | SHENZHEN; | Flash: | Flash; |
Warm Reminder
The above price is not including any 3G, 4G module.
That means that if you want to use SIM card to dial out Internet, you need to order 3G or 4G module.
Basic | |
Operation Mode | LTE Router, Normal Wireless Router, VoIP Gateway |
Mobile Network Type | FDD-LTE cat4 (800/900/1800/2100/2600MHz); TDD-LTE cat4 (1900/2350/2500/2600MHz); WCDMA (900/1900/2100MHz); |
Rate | Downlink/Upstream: 150Mbps/50Mbps |
WIRELESS | |
Wireless Standard | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Wireless Speed | 11n speed up to 300Mbps |
Wireless Frequency Range | 2412 MHz – 2835MHz |
Transmit Power | <20dBm(EIRP) |
Wireless Security | 64/128-bit WEP/WPA-PSK/WPA2-PSK/TKIP/AES |
Wireless Features | Guest Network, Wireless Bridge, MAC Filter |
SOFTWARE | |
VPN Support | IPSec /PPTP /L2TPPass-through; IPSec VPN |
Security Support | PAP/CHAP Authentication for PPP mode NAT forFirewall, SPI Firewall with DoS protection ALG for NAT/PAT support Parental Control, IP Filtering and MAC Filtering 2 Level (User/Admin) Authentication to Router |
Management Support | Web Based GUI, Remote Access Control, TR-069 FTP/HTTP, Telnet, Command Line Interface via serial interface Diagnostic Test, Firmware upgrade-able |
HARDWARE | |
Physical Interface | 1 x USIM port 4 x 10/100Mbps Auto MDI/MDIX RJ45 LAN port 1 x power interface |
LED Indicators | ower,WIFI,3G/4G,WAN,LAN |
Buttons | RESET |
Antenna | 2 external 5dBi antennas |
Power | 12V DC/1A or 5V DC/1A (for the device without built-in battery) |
Processor | QUALCOMM MDM9207 |
Memory | 256MB Flash, 128MB RAM |
Maximum Connected Users | 32 |
Package Content | 1 xLCPE-SKU1, 1 x RJ45 Cable, 1 x Power Adapter, 1 x Quick Installation Guide |
Ø Multimode LTE Chipset,,Support word mode network, TDD-LTE/FDD-LTE/UMTS/EDGE/GSM
Ø WiFi MIMO 2*2,up to 300Mbps
Ø LTE Ca4 MIMO 2*2,up to 150Mbps
Ø 3 RJ45 for LAN and 1 RJ45 for WAN
Ø Up to 32 users access to WiFi
TOM Electronic Technology (Shenzhen) Co., LTD (TOMETEK) established in 2013, located at Shenzhen, China. TOMETEK focuses on the research & development of enterprise-level wireless data access technology & WiFi & Software Router technology which delivers professional Access Point, WiFi Router, CPE , software Router products and solutions to emerging market by carriers and broadband internet service providers. With excellent R&D team (RF engineering/ Antenna engineering / drivers and application engineering / Mechanical design engineering / production management) which improves constantly on product and service quality and customer satisfaction, and creates value for our customers.
1.Do you provide customer LOGO?
Yes, we can provide customer LOGO on firmware and hardware.
2.Do you accept PCBA orders only?
Of course, as a OEM/ODM manufacturer, we can provide PCBA in a short time with good quality.
3.Do you provide firmware support?
Sure thing, unlike other companies which are buying solutions from design company, we have our own firmware development team to support you in 100%.
Just Email or Skype me if any queries,we will reply to you asap,if urgent,pls call me directly.
