Non-woven Pleats-carding Machine for Japanese car air filter

Supplier: Hebei Leiman Filter Material Co., Ltd.
Region: Hebei, China
Contact: Ms Maggie Zhang
Price: $4000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Condition:	New;	Length:	1340mm;
Selling Units:	Single item;	Weight:	200kg;
Package Preview:	https://sc01.alicdn.com/kf/HTB1lIpkbsvrK1Rjy0Feq6ATmVXaq.jpg_640x640.jpg;	Type:	LMRB-1;
Efficiency:	3psc/min;	Porosity:	normal;
Construction:	Cartridge Filter;	Height:	1470mm;
Width:	760mm;	After-sales Service Provided:	Field maintenance and repair service;
Application:	making filter;	Single gross weight:	200 KG;
Warranty:	1 year;	Material:	non woven;
Dimension(LWH):	13407601470mm;	Package:	Wooden package;
Single package size:	134X76X147 cm;	Certification:	ISO9001-2008;
Applicable Industries:	Advertising Company;	Suitable for:	Japanese car air filter;
Place of Origin:	Hebei China;	Package Type:	Wooden package (Non-woven Pleats-carding Machine for Japanese car air filter);
Product name:	Non-woven Pleats-carding Machine;	Brand Name:	Laiman;
Service:	Professional;

Non-woven Pleats-carding Machine for Japanese car air filter

LMRB-1 Non-woven Pleats-carding Machine for Japanese car air filter

Specification
1,Product compatibility:3psc/min
2,width of elements:380mm
3,diameter of elements:900mm
4,main power:0.46kw
5,Working air pressure:0.6mpa
6,Power supply:380v/50Hz
7,M/C size:1340×760×1470(L×W×H)
Material dimension:500×480×770(L×W×H)
8,M/C weight:200kg

Applications
1,This machine has the feeding,Cut off the,Fold the spacing,Folding length,the integration of automatic control.
2,This machine is simple with high efficiency.

Nonwoven filter clot

Compositions		PPS(Polyphenylene sulfide) fiber
Weight(g/m²)		500~550
Thickness(mm)		1.8~2.1
Air permeability(m³/ m²/min)		12~10
Tension at break (N/5×20cm)	Warp	>1100
	Weft	>1200
Tensile Elongation ( % )	Warp	<35
	Weft	<55
Prohibited to use temperature		Below the dew point
Working Temperature (℃)	Continuous	170~190
	Instantaneous	<220
Anti-acid		Super
Anti-alkali		Super
Anti-abrasion		Good
Post—treatment		Size-fixing at high temperature, thread burning, dipping, coating etc

Contact us to for more.

CERTIFICATE

OUR FACTORY

PROMISE

PAYMENT & SHIPPING

Payment

Payment terms: Western Union, Money Gram, T/T,L/C

30% advance, the balance paid before packing

Please remember to leave the correct contact information for delivery.

Shipment

Shipping terms: DHL, UPS, FEDEX, TNT, EMS

Port is Tianjin ,Qingdao, Shanghai or as requests.

COOPERATIVE POLICY

Our cooperative policy

1. Making the sample until you are satisfied with it.

2. Providing production schedule photos to ensure you know every process.

3. Offering professional one-on-one service and replying your E-mail within three hours

4. Shipment sample for checking before shipment.

5. Priority to get the our latest product information after our cooperation

15 days is on approval 10000 kilometers is replaceable

15 days is on approval 10000 kilometers is replaceable, the details are as follows

Logo is greater difference with the confirmation sample

Material is greater difference with the confirmation sample

Design is greater difference with the confirmation sample

FAQ

Q: What's the MOQ(Minimum Order Quantity)?
A: All filter products : MOQ = 300 pcs

Q: Could we apply samples?
A: You can easily contact us by E-mail, Skype, or telephone to make further arrangement for our samples.

Q: What's your terms of packing?
A: Covered with PE bags, outer brown carton and we could be customized for your request.

Q: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.

Q: What are the payment terms?
A: T/T, Western Union, Cash, L/C. First time buyer transaction: Cash Payment or at least 7 days at sight. Please pay some deposit of payment in advance, if payment ≥ 35,000 USD, 30% deposit in advance, balance before shipment.

Q: What is your loading port, terms of delivery and delivery time?
A: 1. Ningbo Port 2. FOB 3. Generally two weeks upon two weeks upon receipts of the deposit. If you have special requirement of delivery, please let us know.
