Wholesale New Technology High Efficiency Plastic Agglomerator machine

Supplier: Ningbo Lvhua Plastic & Rubber Machinery Industrial Trade Co., Ltd.
Region: Zhejiang, China
Contact: Ms nicole song
Price: $10700.00 /set
Min. Order: 1 set

Click here to contact

Product details

Motor power:	90kw;	Capacity:	300kg;
Volume:	500L;	Weight:	2500kg;
Dimension(LWH):	23009501700;	Voltage:	Customized;
Model:	LDZ-500;	Packaging Detail:	FILM PACKAGES;
Applicable Industries:	Manufacturing Plant;	Capacity:	300-350kg/h;
After-sales Service Provided:	Field maintenance and repair service;	Place of Origin:	Zhejiang China;
Certification:	CE ISO;	Warranty:	1 Year;
Power:	90kw;	Type:	Recycling Granulator;
Supply Ability:	30 Set/Sets per Month;	Voltage:	Customized;
Weight:	2500kg;	Condition:	New;
Port:	NingBo;	Brand Name:	Lvhua;
Material:	Iron plus stainless steel;	Size:	20008501600;
Payment Terms:	L/C,T/T;

Product Description

Feature:

1.It has cylinder regulating value.

2.It adopt pure copper motor.

3.Long service life.

4.easy to operate

Production information:

Plastic Agglomerator can directly recycle the waste plastic films and other products less than 2 mm wall thickness into granules, like films made of soft PVC, HDPE, LDPE, PP and other thermo plastics. When the waste plastic is put into the chamber, it will be cut into smaller chips due to the crushing function of the rotating knife and fixed knife.

During the crushing processing, the material that soaked up lots heat from the frictional movement of material being crushing and the material will be going to become semi-plasticizing state.

Before it sticks each other completely, the cold water pre-prepared is sprayed into the material being crushed. So the material being crushed will become small particles or granules.

Working Principle:

When the waste plastic is supplied into the chamber of such machine, it will be cut into smaller chips due to the crushing function of the rotating knife and fixed knife. During the crushing processing, the material that soaked up lots heat from the frictional movement of material being crushing and the wall of container will be going to become semi-plasticizing state. The particles will stick with each other due to the function of plasticization. Before it sticks each other completely, the cold water pre-prepared is sprayed into the material being crushed. The water will be evaporated off quickly and the surface temperature of material being crushed drop down quickly also. So the material being crushed will become small particles or granules. It is easy to recognize the particles by different size and can be colored by using of color agent being putted into the container during the crushing processing.

Parameter trable

Model	Power (kw)	Weight(kg)	Out put (kg/h)	*Size(LWD)*	Effective volume(L)
LDZ-100	37	1000	60-100	1700750-1500	100
LDZ-200	45	1200	100-150	17008501500	150
LDZ-300	55-75	1800	150-300	20008501600	225
LDZ-500	90	2500	300-350	23009501700	500
