Single Flange Pneumatic Powder Butterfly Valve DN250 for Cement Silo
-
Supplier: Jiangsu Cunrui Metal Products Co., Ltd. -
Region: Jiangsu, China -
Contact: Mr Jerry Chen -
Price: $100.00 /piece -
Min. Order: 1 piece
| Inspect & Test: | API 598; | Model Number: | D71X; |
| Characteristic: | Concentric Butterfly Valve; | Brand Name: | CUNRUI; |
| Pre-Temp. Rating: | ASME B16.34; | Media: | Gas; |
| Ends Connection: | Wafer, LUG or Flanged; | Supply Ability: | 1000 Ton/Tons per Year; |
| Structure: | Butterfly; | Place of Origin: | Jiangsu China; |
| Payment Terms: | L/C,T/T; | Standard or Nonstandard: | Standard; |
| Port Size: | DN50~DN1400, 2"~56"; | Type: | Butterfly Valves; |
| Temperature of Media: | Normal Temperature; | Certificate 1: | DNV CE 0575; |
| Packaging Detail: | Standard Export worthy duly wooden boxs; | Application: | Oil, Gas, Water; |
| Certificate 2: | ISO 9001: 2008; | Port: | Shanghai/Ningbo Port; |
| Power: | Manual; | Certificate 3: | API 600; |
| Design & Manufacture: | API 509, DIN 3202; | Face To Face: | API 509, DIN 3202; |
| Product Name | API 509 Lug Flange Cast Ductile Iron Stainless Steel Concentric lever operated Wafer Type Butterfly Valve | |||
| Valve Type | Concentric Butterfly Valve | |||
| Size Range | DN50~DN1400, 2"~56" | |||
| Pressure Range | PN6~PN16, CLASS150 | |||
| Connection End | Wafer, LUG or Flanged | |||
| Standard | API 509, DIN 3202, API 598 | |||
| Operation Way | Manual, Pneumatic Actuator, Electric Actuator | |||
| Packing Method | Standard Export worthy duly wooden boxs | |||
| Shipment Way | By Express, By Air or BySea, as customer request | |||
Construction is as follows:
- Concentric Type
- Single Type Body
- Soft Seated
- Double Half Stem
- Through Stem With Pin
- Uni-direction or Bi-direction
- Flanged Ends to ASME B16.5
- Wafer or Lug Suit to Flanged(ASME B16.5 or B16.47)
Main Part & Materials
| Part Names | Part Materials | ||||||
| Body | Cast Iron | Ductile Iron | |||||
| A126 B | GG25 | FC 20 | A536 | A395 | GGG40 | GGG50 | |
| Disc | Ductile Iorn/CF8/CF8M/CF3/CF3M/Alum-Bronze | ||||||
| Stem | SS410/SS420/SS416/SS304/SS316/Monel | ||||||
| Seat/Seat Ring | NBR/EPDM/PTFE | ||||||
| Packing | Graphite/PTFE | ||||||
| Gasket | SS304+Graphite/SS304+Graphite | ||||||
| Suitable Medium | Water, Waste Water, Sewage | ||||||
| Suitable Temperature | -29~150 °C | ||||||
More producrt>>>>
*****If you want to know more products please click on the picture above,thanks!*****
JiangSu CuiRui Metal Products Co., Ltd Is Located In Jiangsu Province Wuxi City, The Large South Stainless Steel Markets In China, Is Also One of the Powerful Company In the Stainless Steel Area With Large Scale And Long History. We Have 2000 Square Meters Of Storage And Processing Center Which Covered Equipment Using In Slitting, Cutting In horizontal, Laser Cutting , Plasma And Grinding Machine And Embossing Machine. We Mainly Sell Stainless Steel Sheet, Pipes, Coils, Bands, Section Bars, And So On Which Are Applied In Decoration, Medical Industry, Food Industry, Construction Industry etc, Besides, we also sell different kinds of valves. And Have Gained Gain Good Feedback And Establish Mutual Trust With Our Clients. According To Your Requirement We Can Process Brushed Film, 6k, 8k Mirror, Polishing, Yellow Titanium, Black Titanium, Rose Gold, No Fingerprint, And All Kinds Of Colored Stainless Steel Sheet.
1. To provide professional technical guidance and design solution
2. Strict quality control system and rich manufacturing to make sure the hign-quality products
3. Competitive costs supported by stable raw materials suppliers
4. Strong overseas sales team to assist customers to develop sales strategy
5. Fast, efficient and professional online service, like email, skype, whatsapp tools
6. OEM/ODM services
7. Any kind of logo printing or design are available
8. Our company was awarded with ISO 9001, certificate and CE for our valve, pipe fitting and flange products
*************************************************************************************************************************************
1. Q: Is sample order acceptable?
A: Yes
2. After-sales service
1 year warranty for all kinds of products
As an experienced manufacturer, you can rest assured of the quality and sales service
3. Payment
T/T, Paypal, L/C
4.Transportation
Transported by DHL, UPS, EMS, Fedex, SF, by Air, by Sea
5. Do you provide free sample?
Usually we do not offer free sample
6. Could you print our company LOGO on the nameplate and package?
Yes, we can do that
7. Do you accept custom design on size?
Yes, if the size is reasonable
Thanks for your valued time with interest!
-
