Power(W): | 8; | Brand Name: | WEHO; |
Showroom Location: | None; | Place of Origin: | Guangdong China; |
Function: | making different shape small wood pieces; | Key Selling Points: | High Productivity; |
Package Type: | Film or wooden box; | Max. Turned Length (mm): | 200 mm; |
Control system: | 4 servo motor; | Single gross weight: | 800 KG; |
Service supporting: | video and spare parts; | Max. Length of Workpiece (mm): | 1000 mm; |
Warranty: | 1 year; | Single package size: | 320X110X160 cm; |
Warranty: | 1 year; | After Warranty Service: | Video technical support,Spare parts; |
Selling Units: | Single item; | Applicable Industries: | Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Construction works ; |
Working diameter: | 25-58; | Power (kW): | 4 - 8; |
Application: | wood beads Chess toys craft; | Product name: | Wood Cnc Turning Lathe; |
Weight (KG): | 800; | Max. Swing Diameter (mm): | 58 mm; |
Advantage: | automatic feeder; | Usage: | back knife turning lathe; |
Voltage: | 380; | After-sales Service Provided: | Free spare parts; |
Condition: | New; | Local Service Location: | None; |
beads, barrels, various Buddha head pagodas, gourd pendants, gourd pieces, wood rhinoceros horn cups, bowls, whip, cigarette holder, eggs, ashtrays, scroll heads.
Model | MC5865 |
Max. working Diameter | 58mm |
Max. length | Raw material longest 650MM |
Max. spindle shaft speed | 2800 rpm |
Barometric pressure | 0.5-0.8MPa |
Incoming total power | 8kw |
Working speed | 5000pcs per day |
Dimension (LxWxH) | 3400x1200x1400 |
Weight | 800KG |
WEHO Machinery is an original equipment manufacturer, all machines can be custom built to the customer requirements. We can design and manufacture most of wood processing machines.
