Portable Name Tag Engraving Marking Machine Metal Parts Dot Peen Marker

Supplier: Perfect Laser (Wuhan) Co., Ltd.
Region: Hubei, China
Contact: Ms Nicole Bai
Price: $1000.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

Machine Type:	Dot Peen Marking Machine;	Product name:	metal tag engraving machine;
Voltage:	220V 110V 50HZ 60HZ;	Weight:	65kg;
Working area:	150100mm 200300mm 300400mm 400500mm or customized size;	Application:	metal;
Local Service Location:	None;	Warranty:	1 year;
Engraving Speed:	1-3 words/s;	Lifting Range:	300mm lifting;
Marking Accuracy:	0.01mm;	Applicable Industries:	Garment Shops,Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Food & Beverage Factory,Food Shop,Printing Shops,Advertising Company;
Brand Name:	perfect laser;	Key Selling Points:	Flexible Manufacturing;
Packing:	wooden case;	Milling Cutter Diameter:	0.05-1.0mm;
Rated Power:	300w;	Condition:	New;
After-sales Service Provided:	Free spare parts,Field installation, commissioning and training,Field maintenance and repair service,Video technical support,Online support;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Pin Hardness:	HRA92 metal;	Certification:	CE, ISO9001-2000,FDA;
Showroom Location:	None;	Main Axle Rotational Speed:	3000mm/s;
Weight:	60kg;	Port:	Shanghai, Wuhan;
Feeding Height:	10mm;	Dimensions:	0.420.370.42m;
Packaging Detail:	Polywood Case for CNC pneumatic marking machine for metal nameplate;	Place of Origin:	Hubei China;
After Warranty Service:	Video technical support,Online support,Field maintenance and repair service;	Marking Depth:	0.1-2mm;

Portable Name Tag Magnetic Engraving Machine Metal Parts Dot Peen Marker

(Model:PEQD- 030 )

Product Description

Marking automatically with whatever characters,such as Chinese,English,graphic,serial number,

Smart and portable,easy to carry
Numerous option for fonts,supporting edit fonts
Marking depth is adjustable by controlling the marking pin

Technical Data

Machine Model	PEQD-030
Machine Type	Rotary LCD Dot Peen Marking Machine
Standard Marking Area	150mm×100mm
Optional Marking Area	135mm×20mm / 90mm×20mm / 125mm×20mm
Marking Depth	0.01~2mm
Marking Speed	≤50mm/s (for characters height of 3mm / 3-4 numbers /second)
Lifting Range	0-300 mm
Marking Accuracy	0.01 mm
Pin Hardness	HRC 73
Power Supply	220V±10%, 50HZ
Air Pressure	0.2-0.6 Mpa
Machine Power	≤400 W
Working Environment	-5~40 ℃
Whole Machine Weight	60kg

Machine Details

Application areas

Machine Features

Company Introduction

We, Perfect Laser, As a 21 years history industrial equipment manufacture in laser field, 10 year Golden Supplier in Alibaba, with TUV/ISO/FDA, we aims to make high quality products, and also our products have been exported to more than 180 different countries and areas.
