Material: | steel; | GVW: | 2000KGS; |
Surface Treatment: | Hot dipped galvanized; | Wheel: | 185R14C; |
Size: | Customized; | Axle: | 50mm Solid Square Bearing; |
Truck Model: | Foton; | Coupling: | 50mm AU / 17/8 NZ STD coupling; |
Supply Ability: | 600 Set/Sets per Month; | OEM No.: | swt1; |
Payment Terms: | L/C,T/T; | Packaging Detail: | FLAT PACKING; |
Floor: | Check Plate /Wire Mesh; | Lights: | Led Lights; |
Side: | 50x50mm Steel Tube; | Port: | SHANGHAI; |
Type: | Brake Drum; | Drawbar: | 100x50mm RHS; |
Electric brake drum for trucks on hot sale
Different Sizes For Mesh Deck Car Trailer | |||||||
SIZE | MODEL NO | OVERALL SIZE | DECK SIZE | SPRING | WHEEL | SURFACE TREATMENT | GVW |
12x6Ft | SWT-CT126 | 5370x2330x800mm | 3660x1830mm | 7leafs | 185/70R14C | Hot Dipped Gal | 2000KGS |
14x6Ft | SWT-CT146 | 5980x2330x800mm | 4270x1830mm | 7leafs | 185/70R14C | Hot Dipped Gal | 2000KGS |
16x6Ft | SWT-CT166 | 6890x2330x800mm | 4880x1830mm | 7leafs | 185/70R14C | Hot Dipped Gal | 2000KGS |
Description For 12x6 Mesh Deck Car Trailer | |
Drawbar | 100x50x4mm RHS. 1600mm long with 10mm safety chain (AS4177 stamp) |
Chassis | 100X50x3mm RHS (Not angle) |
Floor | Wire Mesh /Checker plate (Not cheap Ribbed zinc plate) |
Side | 50x50 Square tube |
Axle | 50mm Solid square, disc brake for front axle |
Spring | 7leafs rocker roller suspension (not 5leafs or 6leafs cheap & light spring) |
Wheel | 185R14C wheel with 14inch white paint rim |
Jockey wheel | 6inch top wind heavy duty jockey wheel. E-mark & DOT certificateD |
Coupling | 50mm AU STD coupling, 1 7/8 NZ STD coupling, EU STD coupling |
Lights | Led Lights with 7pin plug and 7 core wiring. E-mark &DOT certificateD |
Surface Treatment | Hot dipped galvanized |
