Electricity Type: | AC; | Port: | ningbo/shanghai; |
Packaging Detail: | export standard package; | Model Number: | 3TF40; |
Main Circuit Rating Current: | 40A; | Main Circuit Rating Voltage: | 380V; |
Brand Name: | FULL; | Supply Ability: | 1000000 Piece/Pieces per Month; |
Phase: | 3; | Place of Origin: | Zhejiang China; |
certificate: | CE; | Number of Pole: | 3; |
Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,O/A; |
CJX2(LC1-D) AC CONTACTOF | |||||||||||||
Type | LC1-D09 | LC1-D12 | LC1-D18 | LC1-D25 | LC1-D32 | ||||||||
Rated working current(A) | AC3 | 9 | 12 | 18 | 25 | 32 | |||||||
AC4 | 3.5 | 5 | 7.7 | 8.5 | 12 | ||||||||
Ac3 capacity of phase3 squirrel-cage Motor AC3(KW) | 220/230V | 2.2 | 3 | 4 | 5.5 | 7.5 | |||||||
380/400V | A | 5.5 | 7.5 | 11 | 15 | ||||||||
415V | 4 | 5.5 | 9 | 11 | 15 | ||||||||
440V | 4 | 5.5 | 9 | 11 | 15 | ||||||||
500V | 5.5 | 7.5 | 10 | 15 | 18.5 | ||||||||
660/690V | F> S | 7.5 | 10 | 15 | 18.5 | ||||||||
Rated heat current(A) | 20 | 20 | 32 | 40 | 50 | ||||||||
Electrical life | AC4x104 | 20 | 20-15 | 20-7 | 15-7 | 15-7 | |||||||
AC3x106 | 2 | 2 | 2 | 2 | 2 | ||||||||
Mechanical | 20 | 20 | 20 | 20 | 20 | ||||||||
Number of the contact | 3P+NO | ||||||||||||
3P+NC | |||||||||||||
Type | LC1-D40 | LC1-D50 | LC1-D65 | LC1-D80 | LC1-D95 | ||||||||
Rated working current(A) | AC3 | 40 | 50 | 65 | 80 | 95 | |||||||
AC4 | 18.5 | 24 | 28 | 37 | 44 | ||||||||
Ac3 capacity of phase3 squirrel-cage Motor AC3(KW) | 220/230V | 1.1 | 15 | 18.5 | 22 | 25 | |||||||
380/400V | 18.5 | 22 | 30 | 37 | 45 | ||||||||
415V | 22 | 25 | 37 | 45 | 45 | ||||||||
440V | 22 | 30 | 37 | 45 | 45 | ||||||||
500V | 22 | 30 | 37 | 55 | 55 | ||||||||
660/690V | 30 | 33 | 37 | 45 | 45 | ||||||||
Rated heat current(A) | 60 | 80 | 80 | 125 | 125 | ||||||||
Electrical life | AC4x104 | 10-7 | 7 | 7-6 | 7-5 | 7-5 | |||||||
AC3x106 | 2 | 2 | 1.6 | 1.6 | 1.6 | ||||||||
Mechanical | 20 | 20 | 20 | 20 | 10 | ||||||||
Number of the contact | 3P+NC+NO |
QUESTION AND ANSWER:
1. What's the payment term?
We accept T/T, L/C, D/P, WEST UNION, PAYPAL, CASH
2. What's the production ability?
4HQ containers monthly and rush order for any quantity.
3. What is the standard of package?
Export standard package or special package with requirement
4. Do you accept OEM business?
We accept OEM with your authorization.
5.How is the after-sale service?
We offer spare parts accordingly and English-speaking engineer offer online service.
6.Which market do you already sell?
We already ship to many South America, African countries, Middle East, Southeast Asia etc.
7. what kind of certificate you have?
We have CE, ISO90001 etc.
