Condition: | New; | Port: | Qingdao, Tianjin, Shanghai, etc.; |
Place of Origin: | Henan China; | Installation Dimension: | 800*3300mm; |
Showroom Location: | None; | After Warranty Service: | Video technical support,Online support,Spare parts,Field maintenance and repair service; |
Filling ratio: | 0.67; | Stir mixing tube geometry capacity: | 3.6m3; |
Supply Ability: | 50 Set/Sets per Month Self Loading Concrete Truck; | Local Service Location: | None; |
Certification: | ISO9001; | Tilting Angle: | 15°; |
Applicable Industries: | Building Material Shops,Manufacturing Plant,Construction works ; | Power(W): | /; |
Packaging Detail: | Export standard container: 20GP or 40GP, 40HQ, FR container in bulk, the spare parts in wooden or iron case according to the size and weight. Or packing as customers' request.; | Rotating Speed: | 0-10r/min; |
Payment Terms: | T/T,Western Union; | Mixing drum transmission capacity: | 2m3; |
Dimension(L*W*H): | 3510*1550*1780 mm; | After-sales Service Provided: | Video technical support,Field installation, commissioning and training,Field maintenance and repair service,Online support; |
UNIQUE SELLING POINT: | Easy Maintenance; | Weight: | 1215kg; |
Brand Name: | Huaning; | Warranty: | 1 YEAR; |
Material: | Manganese steel plate; |
Parameter | HJGY.2 |
Mixing drum transmission capacity | 2m³ |
Stir mixing tube geometry capacity | 3.6m³ |
Axis titl | 15° |
Feed rate | ≥3m³/min |
Discharge rate | ≥2m³/min |
Discharge residual rate | 0.5% |
Tank material | Q345B |
Tank thickness | 4mm |
Tank diameter | φ1550mm |
Dimensions(LxWxH) | 3510*1550*1780mm |
Weight | 1215kg |
