Plasma Cnc Pipe 5 Axis Beveling Cutting Machine

Supplier: Jinan Huafei Cnc Machine Co., Ltd.
Region: Shandong, China
Contact: Ms Belinda Hao
Price: $12000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Material / Metal Processed:	Stainless Steel,Carbon Steel,Aluminium Alloy,Aluminum;	Control system:	IPC CNC;
Weight (KG):	2000;	Cutting mode:	Plasma Cutting+ Flame Cutting;
Drive mode:	AC servo motor;	Loading capacity:	max 6t;
After-sales Service Provided:	Free spare parts,Field installation, commissioning and training,Field maintenance and repair service,Online support,Video technical support,Engineers available to service machinery overseas;	Applicable Industries:	Manufacturing Plant;
Cutting Thickness (mm):	50;	Port:	Qingdao, Plasma Cnc Pipe 5 Axis Beveling Cutting Machine;
Key Selling Points:	High-accuracy;	After Warranty Service:	Video technical support,No service,Online support,Spare parts;
Control panel:	industrial touch screen HMI;	Warranty:	1 YEAR;
Packaging Detail:	plastic film cover, or plywood case; Plasma Cnc Pipe 5 Axis Beveling Cutting Machine;	Automation:	Automatic;
Name:	Plasma Cnc Pipe 5 Axis Beveling Cutting Machine;	Diameter:	50-800mm;
Brand Name:	HUAFEI;	Supply Ability:	200 Set/Sets per Year;
Condition:	New;	Dimension(LWH):	12000mm;
Certification:	CE ISO;	Voltage:	380V;
Showroom Location:	Egypt,Canada,Turkey,United Kingdom,United States,Italy,France,Germany,Viet Nam,Philippines,Brazil,Peru,Saudi Arabia,Indonesia,Pakistan,India,Mexico,Russia,Spain,Thailand,Morocco,Kenya,Argentina,South Korea,Chile,UAE,Colombia,Algeria,Sri Lanka,Romania,Bangladesh,South Africa,Kazakhstan,Ukraine,Kyrgyzstan,Uzbekistan,Tajikistan,Japan,Malaysia,Australia;	Rated Power:	5.5Kw;
Place of Origin:	Shandong China;	Payment Terms:	L/C,T/T,Western Union;
Control axis:	3-5;	Bevel angle:	±45°(adjustable);
Local Service Location:	Egypt,Canada,Turkey,United Kingdom,United States,Italy,France,Germany,Viet Nam,Philippines,Brazil,Peru,Saudi Arabia,Indonesia,Pakistan,India,Mexico,Russia,Spain,Thailand,Japan,Malaysia,Australia,Morocco,Kenya,Argentina,South Korea,Chile,UAE,Colombia,Algeria,Sri Lanka,Romania,Bangladesh,South Africa,Kazakhstan,Ukraine,Kyrgyzstan,Uzbekistan,Tajikistan;

Plasma Cnc Pipe 5 Axis Beveling Cutting Machine

Product Overviews

5 Axis Cnc Plasma Pipe Cutting and Beveling Machine

QGVI series numerical control pipe intersecting line cutting machine is a kind of equipment for automatic calculation and cut off at the end of steel pipe. The machine can be widely used in shipbuilding, construction, petrochemical, machinery, metallurgy and other industries of the pipeline structure cutting process. There are a large number of pipes with intersecting line hole, intersecting line ends in these industries, also commonly known as "small shrimp section" of the elbow; this kind of processing in most production is using making sample, marking, manual lofting, manual cutting, manual polishing backward, complicated method. QGVI series CNC pipe cutting machine produced in our factory is very convenient to cut such artifacts, and workers without programming, only need to input the matched radius and the intersection angle parameters of the tube, the machine will automatically cut the pipe intersecting lines and intersecting holes, and the welding groove, does not need manual polishing.

QGVI series CNC pipe cutting machine adopts cylindrical coordinate system numerical control; the control shaft number is 5 axes. With Chinese / English interface, input parameters and man-machine dialogue function, fixed angle bevel cutting function, variable angle bevel cutting, pipe roundness and eccentricity compensation, automatic ignition, on-line and off-line preheating, perforated function, automatic control functions such as cutting speed change.

QGVI series CNC pipe cutting machine numerical control interface with graphics and data, the operation is very simple: the operator only needs to input the parameter of the pipe and the branch pipe, the intersection angle, the cutting speed and so on into the computer, then press the "start" button, and can carry out automatic ignition, preheating, cutting and other automatic operation. In the software, a reasonable cutting guide wire is designed to ensure the quality of the cutting surface, and the parameters after each cutting can be saved as a file.

QGVI series CNC pipe cutting machine cutting way according to the requirements of users can choose the oxyacetylene cutting, oxygen LPG cutting or plasma cutting. The maximum and minimum cutting diameter and pipe length can be designed and manufactured according to user requirements

5 Axis Cnc Plasma Pipe Cutting and Beveling Machine

Main Parameter 5 Axis Cnc Plasma Pipe Cutting and Beveling Machine

No.	Item	Parameters
1	Cutting diameter	Φ 50-Φ800mm
2	Cutting thickness	acoording to plasma source; 6-50mm(flame)
3	Cutting speed	10-1500mm/min
4	Control axis	5 axes; Workpiece rotation Cutting head moves axially along the workpiece Torch along the axial direction swing shaft Torch along the radial axis swing shaft Cutting head vertical lifting spindle
5	Bevel angle	Plasma cutting ≤45° Flame cutting ≤60°
6	Length of pipe	500-12000mm
7	Maximum weight of pipe	5000Kg

5Axis Cnc Plasma Pipe Cutting and Beveling Machine

5 Axis Cnc Plasma Pipe Cutting and Beveling Machine
