Lab Knitting Machine Knit Fabric Sample Assessment Of Yarn Uniformity And Dyeing Affinity With LED Display

Supplier: Anytester (Hefei) Co., Ltd.
Region: Anhui, China
Contact: Mr Eric Qin
Price: $1950.00 /set
Min. Order: 1 set

Click here to contact

Product details

Packaging Detail:	Export Standard Wooden Case;	Applicable filament:	POY (customized), DTY, FDY;
Product Type:	fabric sample;	Applicable Industries:	Garment Shops,Energy & Mining;
Package Preview:	;	Type:	knids of patterns;
Computerized:	YES;	Main machine:	1set;
Warranty:	1 YEAR,1 year;	Applicable filament fineness:	25~1000dtex;
Knitting Method:	SINGLE;	Weight:	100kg;
Place of Origin:	China;	Power supply:	AC380V/AC220V 50Hz;
User manual:	1pc;	Knitting Style:	FLAT;
After-sales Service Provided:	Video technical support,Online support;	Display mode:	LED display/Touch screen display;
Packing list:	1pc;	Production Capacity:	200/year;
Dimension(LWH):	72036014500mm;	Power(W):	AC380V/AC220V 50Hz;
Supply Ability:	200 Unit/Units per Year;	Brand Name:	Anytester;
Condition:	New;	Number of needles:	144~300N;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	Number of feeder:	1;
Port:	Any China Seaport;

Product Description

AT250F Series Lab Knitting Machine is specially designed to knit fabric sample of POY, DTY or FDY for the assessment of yarn uniformity and dyeing affinity. It is applicable to various filaments of 30~1000dtex. It is an ideal equipment for dyeing test in knitting factories.

Features

Filament Storage Device for AT250F-II and AT250F-III

★ Equipped with filament storage device;

★ Applicable to various filaments of 25~1000dtex, such as POY, DTY and FDY;
★ Standard needle cylinder has 240 needles; other needle cylinder with different needles are optional;
Relationship between the filament fineness and number of needles are as below:

★ Adjustable running speed up to 300rpm (only for AT250F-III);
★ Automatic knitted fabric tension device;

★ LED display for AT250F-I and -II while touch screen for AT250F-III;
★ Stable and reliable;

Specification

Model	AT250F-I	AT250F-II	AT250F-III
Needle cylinder diameter	¢89mm (3.5inch)
Number of feeder	1
Number of needles	144~300N
Running speed	180r/min	300r/min	10~300r/min, adjustable
Display mode	LED display		Touch screen display
Applicable filament	POY (customized), DTY, FDY
Applicable filament fineness	25~1000dtex
Power supply	AC380V 50Hz, three-phase		AC220V 50Hz, single-phase
Dimensions(L×W×H)	720×360×14500mm	720×490×14500mm	360×720×14500mm
Weight	85kg	100kg	100kg

Filament fineness (dtex)	Number of Needles
25~40	300
35~65	280
50~100	260
NOTE: The standard needle cylinder for this machine has 240needle. If you want another needle cylinder, please inform us before order.

Packing & Delivery

Packaging
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

History

Since 1982 with more than 20 years' experience

Warranty

Two Year Warranty for whole product

Training

Video and user manual for training

Onsite service

Installation and training service is available

Testing service

Free sample testing before order is available

Lead time

15 working days lead time for most product
