Warranty of core components: | 1 YEAR; | Power: | Gasoline 15HP (LIFAN, Manual start); |
Applicable Industries: | farms,Construction works ,Forestry; | Usage: | wood cutting; |
Power (kW): | 5.5kw/7.5kw; | Warranty: | 1 YEAR; |
Packaging Detail: | packing by wooden and iron; | Blade size: | 3670*34*0.9mm (144"*1-1/4"*0.035"); |
Frame: | 4pcs; | After Warranty Service: | Online support,Spare parts; |
Single gross weight: | 35.0 KG; | Weight: | 31kg2/344; |
Key Selling Points: | Competitive price; | Application: | furniture factory; |
Selling Units: | Single item; | Model: | RS31G; |
Brand Name: | Rima; | Certification: | CE; |
Dimension(L*W*H): | 4064*1778*1800mm; | Condition: | New; |
Cutting capacity: | 790*165*3279mm (31"*6.5"*129"); | Use: | wood cutting; |
After-sales Service Provided: | Free spare parts; | Video outgoing-inspection: | Provided; |
Style: | HORIZONTAL; | Type: | Band saw; |
Package Preview: | ; | Local Service Location: | canada,United States; |
Place of Origin: | Shandong China; | Single package size: | 45X25X20 cm; |
Displacement: | 420cc; | Machinery Test Report: | not available; |
Core Components: | MOTOR; | Weight (KG): | 355 KG; |
Voltage: | 220; | Showroom Location: | United States; |
Band Saw Type: | Log Band Saw; | Max.Working Width(mm): | 790; |
Marketing Type: | Hot Product 2019; |
Keeps blade pitch-free in softwoods. Delivers water directly to the blade at the point of entry into the cut. Large custom-molded water bottle with wide-mouth filling port for easy refilling.
Model |
RS26G |
RS31G |
RS26E |
RS31E |
||
Power |
Gasoline 9HP (LIFAN, Manual start) |
Gasoline 15HP (LIFAN, Manual start) |
Electric Motor 5.5KW |
Electric Motor 7.5KW |
||
Displacement |
301cc |
420cc |
400V 50HZ 3phase |
|||
Cutting capacity |
660*178*2794mm (26”*7”*110”) |
790*178*2794mm (31”*7”*110”) |
660*178*2794mm (26”*7”*110”) |
790*178*2794mm (31”*7”*110”) |
||
Frame |
4pcs |
4pcs |
4pcs |
4pcs |
||
Blade size |
3690*34*0.9mm (145”*1-1/4”*0.035”) |
3960*34*0.9mm (156”*1-1/4”*0.035”) |
3690*34*0.9 mm (145”*1.25”*0.035”) |
3960*34*0.9mm (156”*1-1/4”*0.035”) |
||
Standard track size |
4000x900mm (157”x35.4”) |
4000x1030mm (157”x40.5”) |
4000x900mm (157”x35.4”) |
4000x1030mm (157”x40.5”) |
||
Packing |
2080x570x830mm |
2150 x570x830mm |
2080x610x810mm |
2150 x610x810mm |
||
Safe cutting Speed |
13-15s/m |
13-15s/m |
||||
Blade speed |
17m/min |
17m/min |
||||
Distance teeth |
22mm (0.86”) |
22mm (0.86”) |
||||
Blade Wheel Dia. |
480 mm (18.8”) |
480 mm (18.8”) |
||||
Dimension |
4064*1778*1800mm (160”*70”*71”) |
4064*1778*1800mm (160”*70”*71”) |
||||
Weight |
315/355kg |
352/380kg |
||||
40”HC |
63pcs |
63pcs |
||||
Optional: 14HP KOHLER (13.5HP B&S) manual start Spare parts: 1) Track: 2m 2) 128”/144” Blade(STARRETT BRAND) 3) Blade cover 4) Electrical start |
Features:
1.hand forward and backward,hand lifting.
2.Power is gasoline engine and electric motor.
3.Sawing hard wood customer recommends blades.
RIMA is established in 2009,located in Xibeiyu Industry Zone,Laizhou,Shandong,China.
With its strong technique power,complete set of manufacture equipments and experimental devices,advanced CAD R&D means, the company has complete production capaicty from cutting,profiling,welding,maching,paiting to packing.
RIMA has aleady manufactured a full range of high quality implements for the small to medium-sized tractor owners across the world,Such as Front End loader, Backhoe, Mower, rotary tiller, Wood Chipper, Log Splitter, Post Hole Diggers. more than 50 serials and more than 150 models of various implements.
