Brand Name: | OEM; | Single gross weight: | 0.1 KG; |
MOQ: | 1PCS; | Contact Load: | Low Power; |
Weight/pcs: | 0.1KG/PCS; | Usage: | PROTECTIVE; |
Protect Feature: | SEALED; | Single package size: | 10X7X3 cm; |
Frequency: | 50/60HZ; | Voltage Range: | AC/DC12-240V DC12V AC220V; |
Model Number: | GRV8-01; | Time Range: | 0.1s-10s (10%); |
Selling Units: | Single item; | Size: | MINIATURE; |
Place of Origin: | China; | Warranty/guarantee: | 18months; |
Theory: | Voltage Relay; | 2 Function: | overvoltage undervoltage; |
Certifications: | CE CB; | Supply Terminals: | 1SPDT; |
Kelvin QING Oversea Market Manager
Mobile: +86 18658369816(whatApp/wechat) skype: skypeadminister
linkedin: cn.linkedin.com/in/qianweict
Email: sales(at)everfarelec.com www.everfarelec.com www.qianweict.com
Applications
-Protect electrical equipment and motors from over-voltage and under-voltage.
-Normal/emergency power supply switching.
Function Features
-Controls its own supply voltage(True RMS measurement)
-.User may select operation mode through knob.
- Voltage measurement accuracy<1%.
- Relay status is indicated by LED.
- 1-MODULE,DIN rail mounting.
Technical Date
Electrical features
Product Name | Single Phase Monitoring Voltage Relay |
GRV8-01 | Function: Overvoltage or Undervoltage |
GRV8-02 | Function: Overvoltage & Undervoltage |
Voltage Range | AC/DC12-240V DC12V AC/DC24-48V AC220V |
Supply Terminals | A1-A2 |
Output | 1SPDT |
Current Rating | 10A/AC1 |
Voltage Range | 50/60HZ |
Time Delay | Adjustable 0.1s-10s (10%) |
Reset Time | 1000ms |
Standard | EN 60255-1,IEC60947-5-1 |
Protection Degree | IP40 for Front Panel, IP20 for Terminals |
Weight/pcs | 0.1KG/PCS |
Certifications | CE CB |
Warranty/guarantee | 18months |
MOQ | 1PCS |
Everfar Electrical Co.,Ltd - Distinguished by OEM-manufacture, Develop customer's design and sells instruments for measurement ,such as Current Transformer, Panel meter, Shunt ,and Sourcing products. We ONLY produce the EXCELLENT QUALITY items with COMPETITIVE PRICE. We have been on the market since 2007 and we the joint venture by JSELE,QIANWEI,ZIP which are speicalized manufacturers of current transformer, Panel meter, Shunt at 2015. Everfar Electrical Co.,Ltd know this instruments business very well, because of OEM for many biggest brand over the world, Our main oversea market is European, Africa, Asian, we export to over 50 countries and regions, such as the Italy, German, Poland, UK,Russia, Soth Africa, India, Singapore, etc. It is continue adding.. Everfar Electrical Co.,Ltd, has been qualified for ISO9001 and ISO140001, export more than 5 million pcs of
To order Everfar,you may have the doubts:
1) Is Everfar a sourcing company or profesinal manufacturer?
Everfar Electrical Co.,Ltd - Distinguished by OEM-manufacture,
Develop customer's design and sells instruments for measurement ,
such as Current Transformer, Panel meter, Shunt ,and Sourcing products.
We ONLY produce the EXCELLENT QUALITY items with COMPETITIVE PRICE.
We have been on the market since 2007 and we the joint venture by JSELE,QIANWEI,ZIP
which are speicalized manufacturers of current transformer, Panel meter, Shunt at 2015.
2) Can Everfar design and make the mould for special requirements?
Yes,we have the ability to do OEM / ODM to meet clients' requirements.
In the past years,we make new moulds for our customer 10 moulds each year.
3) What is your main market, and who is your main customers?
Our main oversea market is European, Africa, Asian, we export to over 50 countries and regions, such as the Italy,
German, Poland, UK,Russia, Soth Africa, India, Singapore, etc. It is continue adding..
Our main customers are very famouse brands in the instrument business. Send our email, we will talk about this in detail.
4) How does your factory do regarding quality control?
We have many documents to control the quality from the raw material to the completed products.
Our tester is the most mordern type with computer records.
5) What kind of certification do you have for oversea market?
Mainly, we have the CE for selling to oversea market,and have the ISO90001 to control the production.
6)Could I order samples before release a big order?
Yes,you can order in our Alibaba web directly, and special drawings
or design ,pls contact us immediately by email.
