High speed wood bamboo toothbrush making moulding machine

Product details
Production Capacity:12 holes per second;Packaging Detail:PACKING in stronger Iron shelves protection & Splint box;
Single gross weight:650.0 KG;Selling Units:Single item;
After-sales Service Provided:Engineers available to service machinery overseas;Single package size:160X160X195 cm;
Package Preview:;Condition:New;
Applicable Industries:Manufacturing Plant;Warranty:ONE YEAR;
Brand Name:Mxdx;Place of Origin:Guangdong China;

Fully automatic tooth brush machine



Description:
ModelMX-3ATB001
NO. of axis3axis
Qty of headstufting
Application Flat toothbrush.
brush types bush base with holes
Brush base materialsPlastic
Filament materialsPP,PET, Nylon, fiber etc.
The mold fixture size30*15mm
Diameter of hole 1~1.2mm
The length of filament(outside the hole)8~14mm
Colors of Brush Filaments1color or 2 color (3 color for choose)
Parameter:
tufting Speed10 holes/sec.
Power voltage, frequence220/380v , 50/60HZ  (customer choose)
Main motor power0.55kw
Air Source Input0.4~0.5Mpa
Equipment size1100*1200*1300mm
Weight650kg
