Packaging Detail: | PE bag+box+master carton; | Forwarding Mode: | Store-and-forward; |
Communication Mode: | Full-Duplex; | Payment Terms: | L/C,T/T,Western Union; |
Surge Protection: | 6kv; | Model Number: | HP8G2; |
Products Status: | Stock; | MAC Address Table: | 2k; |
Internal Power Supply: | YES; | Ports: | 10; |
Input: | 100-240VAC,50/60Hz; | Uplink port: | 2 Port, 10/100/1000Mbps; |
Brand Name: | HEDY; | Port: | Guangzhou; |
Supply Ability: | 10000 Set/Sets per Month; | Function: | POE; |
PoE port: | 8+2 ports; | PoE Standard: | IEEE802.3af, IEEE802.3at; |
Package Preview: | ; | Certification: | N/A; |
Place of Origin: | Guangdong China; | Transmission Rate: | 10/100/1000Mbps; |
Network Protocol: | IEEE802.3/802.3u/802.3x/802.3az; | Switch Capacity: | 5.6Gbps; |
Packet Forwarding rate: | 1.4Mpps; |
2 ports Giga uplink poe switch 8 port description:
* Product name: 2 ports Giga uplink poe switch 8 port for CCTV camera system
* Built in Power Supply
* Input: 100-240VAC
* 8x10/100 PoE Ports + 2 x10/100/1000 BASE-T Ports
* Individual LED power indicator
* Transmission distance:0~100/250M(the extend distance is adjusted by the code switch)
* Power Budget: 100W
* Warranty: 2 years
poe switch 8 port features:
* Support IEEE802.3 AT standard, Compatible with IEEE802.3 AF;
* not only can transmit data via the network cable, also transmit power;
* Advanced sensing algorithm, Only provide the power supply for the terminals of IEEE 802.3af/ AT standard;
* the distance of Ethernet cable power supply transmission up to 250 meters;
* POE power supply module built-in, easy to install, plug and use;
* Have short circuit protection, when there is heavy electric current and other electrical fault, it will start short-circuit function
poe switch 8 port details:
Model | LP8G2 |
Product | POE Switch-10 Port Fast Ethernet Switch with 8 PoE & 2 Giga uplink Port |
Ports | |
Network Ports: | 10 |
PoE Port: | 8, 10/100Mbps; RJ45 ports; Max. 30W Output of Single PoE Port Transmission distance:0~100/250M(the extend distance is adjusted by the code switch) |
Uplink Port: | 2, 10/100/1000Mbps; Transmission Distance: 0-100m |
Ethernet Port Light | 2pcs(Yellow & Green) on RJ45, Green indicates PoE, Yellow indicates Link Act |
Standard | |
Network Protocol: | IEEE802.3/802.3u/802.3x/802.3az |
Performance | |
Switching Capacity: | 5.6Gbps |
Packet Forwarding Rate: | 1.4Mpps |
Forwarding Mode: | Store-and-forward |
MAC Address Table: | 2k |
Power Over Ethernet | |
PoE Standard: | IEEE802.3af, IEEE802.3at |
PoE Power Supply | 4/5(+),7/8(-) |
Transmission Distance: | Defaulf: 0-100/250M(the extend distance is adjusted by the code switch) |
General | |
Power Source: | Bult-in Power Supply |
Input: 100-240V AC, 50/60Hz | |
POE Power Budget: | 100W |
Power Consumption: | 5W |
Surge Protection: | 6KV |
ESD | Contact Discharge 6KV / Air Discharge Level 8KV |
Anti-Thunder Level | 6KV, Standard: IEC61000 4 5 |
Working Temperature: | -10℃-45℃ |
Humidity: | 5%-95% , non-condensing |
Storage Temperature: | -40℃-85℃ |
Color | Black |
Weight: | 0.74kg(not include input cable & packaging) |
Dimension: | 220*140*40mm |
8 port PoE switch applications:
* CCTV Camera
* DVR/NVR
* Wireless AP
* IP phone
* Notebook
* Other PoE product
