Packaging Detail: | Standard export packing with YBCN brand Client's designed packages OEM packages,or according to the customers; | Silencer size: | 1/8"; |
Voltage: | DC24V AC220V AC110V DC12V; | Single gross weight: | 0.25 KG; |
Place of Origin: | China; | Package Preview: | ; |
Single package size: | 14X7X4 cm; | Working pressure: | 0.05-0.85MPa; |
Condition: | New; | Brand Name: | RIH; |
Model Number: | 4V210-08; | Type: | Valves; |
Name: | RIH DC24V Solenoid Valve 4V210-08; | Selling Units: | Single item; |
Applicable Industries: | Hotels,Garment Shops,Building Material Shops,Manufacturing Plant,Machinery Repair Shops,Food & Beverage Factory,Farms,Restaurant,Home Use,Retail,Food Shop,Printing Shops,Construction works ,Energy & Mining,Food & Beverage Shops,Advertising Company; | Material: | Strong box; |
Warranty: | 1.5 years; | Thread size: | 1/4''; |
2/5 Way Air Compressor DC24V AC220V AC110V DC12V Wiring Solenoid Valve Pneumatic Cylinder Parts Airtac 4v210-08
Specifications:
Model | 4V210-08 | 4V220-08 | 4V230-08 | |
Fluid | Air | |||
Action | Intemally piloted acting type | |||
Valve type | 2/5Way | 2/5Way | ||
Effective area(mm²) | 16mm²(CV=0.89) | 12mm²(CV=0.67) | ||
Port size | ||||
Lubrication | Not required | |||
Operating pressure | 1.5~8.0kgf/cm² | |||
Proof pressure | 10.5kgf/cm² | |||
Ambient&fluid temperature | 5~60°C | |||
Vottage range | ±10% | |||
Power consumption | AC1.3W DC1.5W | |||
Insulation grade | F grade | |||
Protection | IP65(DIN 40050) | |||
Connection | Lead wire type or teminal type | |||
Max.frequency | 5cycle/sec | |||
Min.response time | 0.05sec | |||
Main parts material | Body | Aluminum alloy | ||
Seal | NBR |
Q1: Are factory or trading company?
A1:We are the leading manufacturer of pneumatic products who have 13 years experience. Welcome to visit our factory
at any time.
Q2:Can I get sample?
A2:Yes,We can offer free sample but express charge by your side. In a word, each of your needs are of most valuable
matter for us.
Q3:Do you accept OEM business?
A3:Yes.We do.
Q4:What’s the payment term?
A4: T/T,Western Union,Paypal are applicable for us.
Q5: How about the warranty?
A5: 12 months under normally used.
Q6. What’s the delivery time ?
A6.. Normal model 2-5days,because we have ability to do the stock.For big order,it takes about 10-15days.
Q7: How does your factory dothe quality control?
A7: Quality is important,we always attach importance to quality control from the beginning to the end of the prodution.
Each product will be fully assembled and carefully tested before packing and shipping.
