Image Sensor: | 1/3 Exmor CMOS; | Feature: | video camera full hd 1920x1080; |
Packaging Detail: | Color box with PE Foam ,strong carton international standard packing. Dimension(LXWXH): 260*175*180 mm /296*225*218mm; | Optical Zoom: | 10x - 20x; |
Port: | FOB ShenZhen/FOB GuangZhou/FOB HongKong; | Certificate: | FCC/CE/RoSH; |
Package Preview: | ; | ZOOM: | 20X ZOOM; |
Screen Size: | Without Screen,2" - 3"; | Place of Origin: | Guangdong China; |
High Definition Support: | 1080p (Full-HD); | Imaging Sensor: | CMOS; |
Suitable for: | Video Conferencing/Telemedicine/ Live Streaming; | Resolution: | 1080P(1920*1080); |
Color: | Black; | Effective MegaPixel: | About 2.38MP; |
Brand Name: | Tenveo; | Lens: | F=4.7mm(wide Angle End)~84.6 Mm(far End); |
Brand: | Tenveo; | Model Number: | TEVO-VHD20N; |
Media Type: | HDD / Flash Memory; | Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal; |
Certification: | FCC,ce,RoHS; | Video Output: | USB&SDI&HDMI; |
Supply Ability: | 1000 Piece/Pieces per Week; | Wideangle: | 120°; |
Model No. | TEVO-VHD20N |
Image Sensor | 1/3 inch HD CMOS |
Effective pixel | 2.38 mega pixel(16:9) |
Horizontal Resolution | 1080P60/50/30/25, 1080I60/50/30/25, 720P 60/50 |
Focal length | F=4.7mm(wide)-94.0(tele) |
Signal standard | NTSC/PAL |
Zoom | 20x zoom |
Horizontal view angle | Near-end 55.5°~Far-end 3.0° |
Gain control | Auto/manual |
Focus | Auto/manual |
SNR ratio | ≥50dB |
Shutter speed | 1/1 sec to 1/10000s (22 steps) |
Preset position | Remote-controller supports 9 presets, PELCO Control Protocol supports 256 presets |
Pan/Tilt movement range | Pan: 340°(Max Speed 80°/S), Tilt: 120°(Max Speed 60°/S) |
Control terminal | RS-232, RS485 |
Control Protocol | VISCA, PELCO-D, PELCO-P (RS-232, RS485) |
Video output | 3G-SDI, HDMI,USB |
Noise Reduction | 2D/3D |
Work Temperature | -10°~50° |
Work Humidity | -20°~60° |
Baud rate | 2400/4800/9600/19200bps |
Decoder | Built-in |
Address Set | 1~256 |
Installation | Support desktop, Tripod, Wall mount and Ceiling mount |
1.Main features of the android video conference camera:
3G-SDI/HDMI/USB | HD1080P | 2.38 mega pixel |
20X optical zoom | Pan: 0-355° Tilt :+/-60° | Support desktop, Tripod, Wall mount and Ceiling mount |
2.Main details of the hd-sdi ptz video conference camera:
3.Main application of the hd-sdi ptz video conference camera:
Certifications:
