UNIQUE SELLING POINT: | High operating efficiency; | Exciting Force: | 20KN; |
Dimension(L*W*H): | 1900*915*1450mm; | Condition: | New; |
Video outgoing-inspection: | Provided; | Machinery Test Report: | Provided; |
Travel Speed: | 0-8km/h; | Showroom Location: | None; |
Brand Name: | STORIKE; | Warranty of core components: | 1 Year; |
Core Components: | Motor,Pump; | Hydraulic Valve Brand: | SAUER-DANFOSS; |
Single package size: | 196X96X152 cm; | Weight: | 1200KG; |
Selling Units: | Single item; | After Warranty Service: | Video technical support,Online support,Spare parts; |
Power: | 8100; | EPA certificate: | Approved; |
Engine Brand: | HONDA; | Water tank: | Plastic; |
Vibrating motor: | Denmark Danfoss; | Single gross weight: | 1200.0 KG; |
Warranty: | 1 Year; | Double Driving Motor: | Denmark Danfoss; |
Exciting force: | 20KN; | Package Preview: | ; |
After-sales Service Provided: | Free spare parts,Video technical support,Online support; | Type: | Double Drum Roller,Vibratory Roller; |
Grade Ability: | 30%; | Drum: | Double Drum Roller; |
Place of Origin: | Shandong China; | Certification: | CE ISO9001; |
Drum diameter: | 500MM; | Applicable Industries: | Construction works ; |
Marketing Type: | New Product 2020; | Light: | LED; |
Wheel Size: | 500(d)*800(w)*2mm; | Hydraulic Piston Pump: | USA Sauer; |
Packaging Detail: | China Famous Brand Hydraulic Vibrating Ride On Diesel Gasoline Road Roller EPA; | Local Service Location: | None; |
Hydraulic Pump Brand: | SAUER-DANFOSS; |
1 Ton 2 Ton 3 Ton Fully Hydraulic Vibrating Tandem Asphalt Compactor Road Roller
ITEM NO/DETAILS | ST1000 | ST1000C | ST1000CS |
ENGINE | |||
Engine | HONDA/BRIGGS&STRATTON | CHANGCHAI | GOLDEN FLYING FISH |
Engine Model | GX390/25T2 | 186F | RD90N-1 |
Engine type | Single cylinder, OHV, air-cooled, four-stroke, gasoline | Single cylinder, vertical, air-cooled, four-stroke, diesel | Single cylinder, Horizontal,water-cooled, four-stroke, diesel |
Number of cylinders | 1 | ||
Output power (KW) | 9.7/9.9 | 6 | 5.88 |
Rating speed(RPM) | 3600 | 2400 | |
DRIVING | |||
Electrical equipment(V) | 12 | ||
Drive mode | Variable plunge pump, stepless speed change, double-wheel series, parallel motor | ||
Walking speed (KM/H) | 0--8 | ||
Theoretical climbing ability(%) | 30/35(vibration on/off) | ||
STEERING | |||
Swing angle(°) | 28 | ||
Steering mode | Hydraulic cylinder, articulated steering | ||
Steering system | Swing articulated | ||
EXCITING SYSTEM | |||
Vibration wheel | Front | ||
Drive form | Mechanical Transmission & Electromagnetic clutch | ||
Vibration frequency (HZ) | 70 | 65 | |
Vibration amplitude (MM) | 0.5 | ||
Exciting force(KN) | 20 | ||
SPRINKLING SYSTEM | |||
Water spray form | Electric Intermittent | ||
CAPACITY | |||
Hydraulic oil capacity(L) | 13 | ||
Fuel capacity(L) | 6.5 | 5.5 | 10 |
Water tank capacity (L) | 67 | ||
SIZE | |||
Working width(MM) | 825 | ||
Overall length(MM) | 1870/1780 | ||
Machine height(MM) | 1450/1985 | ||
Turning radius(outer)(MM) | 2600 | ||
Ground clearance(MM) | 245 | ||
Wheel track(MM) | 1230 | ||
Drum size | 500*700mm*2 | ||
Drum thickness(MM) | 12 | ||
WEIGHT | |||
Weight(KG) | 1000 | ||
Static load(N/CM) | 56/77 |
Features:
A):Famous Brand Engine
800KG:
1 Ton Roller:
1.2 Ton Roller:
1.5 Ton Roller
2.0 Ton
3.0 Ton
