RWYL91N Working Weight 3650kg Driving Hydraulic Vibratory Roller

Supplier: Qingzhou Honorsun Heavy Industry Co., Ltd.
Region: Shandong, China
Contact: Mr kecheng han
Price: $7000.00 / 1 - 9 sets
$5500.00 / >=10 sets
Min. Order: 1 set

Click here to contact

Product details

Showroom location:	not any	Video shipment inspection:	if
Types of:	Single Drum Roller, Vibratory Roller	Applicable industries:	Hotels, clothing stores, building materials stores, machinery repair shops, manufacturing plants, farms, construction projects
brand:	Hengsheng	Warranty:	1 year
State of health:	new	Mechanical test report:	if
Marketing Type:	New Products 2020	Packaging Details:	Container bare
Engine brand:	Qian Chai	product name:	vibratory roller
strength:	40kw	Exciting force:	43KN
Local service location:	not any	Level Ability:	55%
weight:	3 tons	Drum Diameter:	1030mm
Dimensions (LWH):	335013502750mm	Driving speed:	0-9km/h
place of origin; place of origin:	Shandong China	Core component warranty:	1 year
drum:	Single Drum Roller	Unique selling point:	High operating efficiency
Core components:	Pressure vessels, motors, bearings, gears, PLCs, pumps, engines, gearboxes	payment terms:	L/C, Western Union, D/P, D/A, T/T
port:	Shanghai, Xiamen, Qingdao, any seaport in China	Supply capacity:	300 sets per month

RWYL91N Working Weight 3650kg Driving Hydraulic Vibratory Roller

Product Description

Riding on the compact roller is a small vibratory roller, suitable for the repair and maintenance of various roads, highways, sidewalks, parking lots, sports fields and garden lawns. It is especially suitable for compacting narrow areas such as pipe trenches and drainage ditches.

Technical Parameters

Types of	RWYL91	RWYL91N
running
speed	0-9km/h
turning radius	2200mm
theoretical climbing ability	55%
to compact
forward/backward static load	130 N/cm
Nominal amplitude	1.6/0.8mm
vibration frequency	41 Hz
Exciting force	85/43KN
Tank volume	67L
Serving
drive	Hydraulic drive
vibration	hydraulic vibration
steering	hydraulic steering
engine
Model	Yanmar 4TNV88	Changchai ZN490B
Types of	Diesel, liquid-cooled, four-cylinder
strength	35kw/3000rpm	40kw/3000rpm
Fuel tank capacity	50L
lubricating oil	6.5L	7L
Fuel consumption	261 g/kWh	268g/kWh
size
Drum width	1200mm
Steel drum diameter	1030mm
tread	1804mm
total length	3350mm
overall width	1350mm
total height	2750mm
Package Size	3450×1550×2240mm
weight
working weight	3600kg/3800kg	3650kg/3850kg
