Packing: | Carton Packing; | Rated current: | 1A,2A,3A,4A,5A,6A,8A,10A,12A,15A,16A,20A,25A,30A; |
Certificate: | CE.TUV.UL; | Product name: | Dc Fuse; |
Payment Terms: | L/C,Western Union,D/P,T/T,MoneyGram; | Material: | Ceramic tube; |
Breaking Capacity: | High; | Standard: | IEC/EN60269.6/TUV; |
Condition: | 100% Original; | Rated voltage: | 1000V DC; |
Port: | Shanghai/Ningbo; | Supply Ability: | 100000 Piece/Pieces per Week; |
Model Number: | YRPV-30; | Usage: | LOW VOLTAGE; |
Packaging Detail: | carton; | Brand Name: | Yinrong; |
Safety Standards: | IEC; | Size: | 10x38mm; |
Place of Origin: | Zhejiang China; | Color: | white; |
Model/Size | Rated Voltage(V) | Rated breaking capacity(kA) | Rated current(In/A) | ||||||||||||||
YRPV-30 | DC:1000 | 40/20 | 2 | 3 | 3.15 | 3.5 | 4 | 5 | 6 | 8 | 10 | 12 | 15 | 16 | 20 | 25 | 30 |
Power consumption(In/W) | |||||||||||||||||
0.85 | 0.99 | 1.0 | 1.15 | 1.2 | 1.3 | 1.48 | 1.76 | 2.2 | 2.3 | 2.6 | 2.7 | 3.2 | 3.8 | 4.25 |
