Original NSK NTN 23072CC/W33 Spherical Roller Bearings

Supplier: Jinan Maolei Bearing Co., Ltd.
Region: Shandong, China
Contact: Ms jiessie zhang
Price: $6.52 / 1 - 99 pieces
$4.50 / >=100 pieces
Min. Order: 1 piece

Click here to contact

Product details

Application:	Mining. Metallurgy. Agriculture. Chemical;	Applicable Industries:	Energy & Mining;
Packaging Detail:	A: tube package + outer carton + pallets B: single box + outer carton + pallests C: tube package + middle box + outer carton + pallets D: According to your request;	Brand Name:	LLH;
Main market:	America;	Service:	OEM Customized Services;
Material:	Chrome Steel;	Number of Row:	Double row;
Package:	Carton;	Payment Terms:	L/C,Western Union,D/P,D/A,T/T,MoneyGram;
Cage material:	Copper Cage Steel Cage;	Place of Origin:	Shandong China;
Precision Rating:	P0 P6 P5 P4 P2;	Structure:	Spherical;
Clearance:	C0 C2 C3 C4 C5;	Type:	Roller;
Feature:	Low Noise. Long Life .high;	Seals Type:	Open;
Model Number:	22209;	Cage:	Nylon Cage;
Certification:	ISO9001:2008;

Spherical roller bearings with two rollers, mainly bear radial load, but also can withstand axial load in either direction. A high radial load capacity, especially suitable for heavy loads or vibration, but can not bear the pure axial load. This kind of bearing outer ring raceway is spherical shape, so the good performance of its self-aligning, can compensate concentricity error.

There are two symmetrical spherical roller, there is a common spherical outer ring raceway, the bearing inner ring with two axis tilt

Angle of raceway, aligning with good performance, when the axis force bent or install a different heart is still bearing the normal use, transfer concentric with the bearing size range varies, generally aligning allowed 1 to 2.5 degree angle load bearing capacity of the larger type, in addition to radial loads but also under way outside the role of bearing axial load, with good impact resistance, in general, self-aligning roller bearings allowed working speed than the low.

Material	Bearing	Chorme steel, carbon steel, Stailness Steel ,ceramic
	Cage	Steel cage, carbon cage, stailness steel cage
Features	Hardness	58-62HRC
	Precision	ABEC1(P0) ABEC3(P6) ABEC5(P5) ABEC7(P4) ABEC9(P2)
	Clearance	C2,C0,C3,C4,C5
	Noises Rating	Z1,Z2,Z3,Z4
	Vibration Rating	V1,V2,V3,V4
	Seal type	OPEN ZZ RS
HS Code
Port	Shenzhenand Shanghai port
Cetificate	ISO 9001:2008, SASO ,CQC
Advantage	1).Excellent and high quality control 2).Prompt delivery 3).Competitive price 4).Small order accepted 5).Customers' drawing or samples accepted 6).OEM service
Application	Mainly used in motorcycle rear axle wheel hub, heavy machine tools' main shafts, big power reduction gears, axletree axle boxes, roller wheels of transportation devices, and the supporting rollers and working rollers of the rolling mills.
process production	1.Assembly 2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging

Bearings NO.	d/mm	D/mm	B/mm	C/kN	C0/kN	Weight/kg
22326 CC/W33	130	280	93	1120	1320	29
22326 CCJA/W33VA405	130	280	93	1120	1320	29
22326 CCK/W33	130	280	93	1120	1320	28.5
22326 CCKJA/W33VA405	130	280	93	1120	1320	28.5
23028 CC/W33	140	210	53	465	680	6.55
23028 CCK/W33	140	210	53	465	680	6.35
24028 CC/W33	140	210	69	570	900	8.55
24028 CCK30/W33	140	210	69	570	900	8.4
24028-2CS2/VT143	140	210	69	570	900	8.55
23128 CC/W33	140	225	68	630	900	10.5
23128 CCK/W33	140	225	68	630	900	10
24128 CC/W33	140	225	85	765	1160	13.5
24128 CCK30/W33	140	225	85	765	1160	13.5
24128-2CS2/VT143	140	225	85	765	1160	13.5
22228 CC/W33	140	250	68	710	900	14
22228 CCK/W33	140	250	68	710	900	13.5
23228 CC/W33	140	250	88	915	1250	19
23228 CCK/W33	140	250	88	915	1v50	18.5

Jinan Maolei Bearing Co., Ltd is a manufacturer and trader specialized in the research, development and production of bearings. is located in the "Spring City" Jinan, with convenient transportation.

The core products of Jinan Maolei bearing Co,.Ltd have a variety of bearings ranging from deep groove ball bearings, self-aligning ball bearings, self-aligning roller bearings, wheel hub bearings, linear bearings, pillow block bearing, ceramic bearings, plastic bearings, cylindrical roller bearings, angular contact ball bearings, tapered roller bearings, thrust ball bearings, thrust roller bearings and needle roller bearings to spherical plain bearings and other products. All of our products comply with international quality standards ISO 9001 and are greatly appreciated in a variety of different markets throughout the world.

We insist on the philosophies of "integrity" and "pragmatic & win-win business". We also adhere to the "people-oriented" and "advancing" enterprise spirit . "Quality first and customers utmost" is honored as our enterprise concept.

1.High speed, High Precision, Low Noise, Long Service Life

2.Wide Array of Applications

3.Large Inventories

4.Small order accept

5.Competitive Prices and High Quality

6.Various Brands

7.Require little maintenance

8. OEM is supported

9. Our company insists on the "quality first, credit first" business ideas and our product specification is well-founded. We have a good reputation in the international market by our perfect service and sufficient supply.

Q: Are you trading company or manufacturer ?

A: We are the manufacture of bearings for more than 20 years, "Quality is our culture".

Q: How long is your delivery time?

A: Generally it is 1-3 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: What causes bearing noise?

A: Bearing noise is a function of both the bearing and the way it is used. Some external factors that affect bearing noise include lubricant type, excessive bearing load, and improper installation. Once the abnormal noise occurred, you can contact our engineers, we will help you find the reasons and provide the appropriate solutions.
