Chassis brand: | MAN; | Horsepower: | 251 - 350hp; |
Fire monitor shoot range: | Water 60m; | Condition: | New; |
Supply Ability: | 500 Unit/Units per Year; | Water tank capacity: | 4400kg; |
Port: | Any China Port; | foam concentrate: | 300/200kg; |
Transmission Type: | Manual; | Brand Name: | XCMG; |
Emission Standard: | EURO 5; | Drive Wheel: | 4X2; |
Payment Terms: | L/C,Western Union,D/P,D/A,T/T,MoneyGram; | Fuel Type: | Diesel; |
Size: | 8960*3570*2500mm; | Packaging Detail: | Comply with export packaging requirements; |
Tank Capacity: | 3001 - 5000L; | Place of Origin: | Jiangsu China; |
Type: | RESCUe; |
XCMG provides cost-effective customized services, the solutions and quotations upon receiving your personalized demand. | ||||||||
Project | Parameter | |||||||
Dimension Parameters | Overall dimensions | Length | 8790 | |||||
Width | 2480 | |||||||
Height | 3480 | |||||||
Axle base mm | 4425 | |||||||
Wheelbase mm | 2066/1802 | |||||||
Front/rear suspension mm | 1400/2400 | |||||||
Front/rear extension m | 0/180 | |||||||
Parameters | Maximum speed km/h | 95 | ||||||
Minimum turning diameter m | 17 | |||||||
Braking length (full load, initial braking speed 30 km/h) m | 10 | |||||||
Approach Angle/Departure Angle | 19/11 | |||||||
Maximum climbing ability % | 25 | |||||||
Parameters | Rated fire extinguishing agent Full load weight | Water kg | 4000 | |||||
Class-B foam kg | 300 | |||||||
Class-A foam liquid kg | 300 | |||||||
Curb weight | Total weight kg | 10680 | ||||||
Front axle kg | 3650 | |||||||
Rear axle kg | 7030 | |||||||
Maximum allowable value Total weight | Total weight kg | 16000 | ||||||
Front axle kg | 6200 | |||||||
Rear axle kg | 10100 | |||||||
Piece Parameter | Type | TGM18.290 | ||||||
Type | II | |||||||
Driving type | 4×2 | |||||||
Manufacturer | MAN's Production, German | |||||||
Type | D0836LFL30 | |||||||
Fuel type | Diesel | |||||||
Displacement/Power mL/kw | 6871/215 | |||||||
Emission level | National IV Standard | |||||||
Manufacturer | MAN's Production, German | |||||||
Steel spring number | 1/3 | |||||||
Tire size | 295/80R22.5 | |||||||
Number of tires (excluding spare tires) | 6 | |||||||
Passengers allowed in the cab | 2+4 |
