New fashion reention dorado 21700 48v 25ah 20ah reention dorado batterie 505 48v 25ah for 500W 750W 1000W motor batterie dorado 21700 Tesla specification:
Model |
Junda-J109 |
Chemistry |
LiNiCoMnO2 |
Nominal Voltage |
48V |
Nominal Capacity |
20ah 25ah |
Weight |
Approx 6.5Kg |
Outer case style |
Inner battery case Dorado 21700 case L440 52pcs or L505 65pcs 18650 cell |
Standard Charge |
Constant Current 0.2C, Constant Voltage 54.6V 100mA Cut-off |
Fast Charge |
Constant Current 0.5CA, Constant Voltage 54.6V 100mA Cut-off |
Standard Discharge |
Constant Current 0.2C/End Voltage 39V |
Cycle Life |
500 times with DOD80% |
Continuous Discharge Current |
20A or customized |
Peak discharge current |
60A or customized |
BMS function |
Over-Current Protection,Over-Discharge Protection, Over-Charge Protection,Short-Circuit Protection, Balance |
Storage Temperature Range |
Temperature: -10-40℃ Relative humidity:45-75% Pressure: 86-106KPa |
New fashion reention dorado 21700 48v 25ah 20ah reention dorado 505 48v 25ah for 500W 750W 1000W motor batterie dorado 21700 Tesla feature:
1 Long Battery Life
2 Easy to Use
3 Safety and Environmental Protection
4 High Discharge Efficiency
5 Over one year warranty
Warning :
1 do not short circuit postive and negative of the battery pack.
2 do not dismantle the battery without the professional ebike battery technicist ' s support.
3 do not place the battery under high tempearature,such as heat,sunshine,or close to fire.
4 do not place the battery in fuilds,such as water ,alkaline or slat water.
5 Please keep the battery cool and dry ,charge the battery for 2 hours every 3 months if stored for a long time.
6 Always charge the battery with the licensed charger for lithium ion or lithium polymer battery.Please never mix the other charger to charge them in case of battery issues.
