Brand Name: | XDR; | Condition: | New; |
Application: | Street Light Maintenance; | Wheelbase: | 3360mm; |
Fuel Type: | Diesel; | Rotation: | 360° hydraulic; |
Dimensions (L x W x H) (mm): | 5950*1980*2930; | Arm Type: | Folding Type; |
Engine Capacity: | < 4L; | After-sales Service Provided: | Onsite Installation,Video technical support,Return and Replacement,Field installation, commissioning and training,Free spare parts,Field maintenance and repair service; |
Place of Origin: | Hubei, China; | Model: | XDR Aerial platform truck with hydraulic booms work platform; |
Telescoping hook: | Available; | Emission Standard: | EURO 5; |
Total Weight: | 4495kg; | Transmission Type: | Manual; |
Horsepower: | < 150hp; | Port: | SHANGHAI/WUHAN; |
Curb Weight: | 4170kg; | Packaging Detail: | WAX; |
Payment Terms: | L/C,Western Union,D/P,D/A,T/T; | Supply Ability: | 500 Units per Month; |
Landing Leg: | 4pcs; | Fuel Tank Capacity: | 100-200L; |
Working Height: | 12m; |
DONGFENG 12M AERIAL PLATFORM TRUCK XDR Aerial platform truck with hydraulic booms work platform | ||||||
Vehicle Parameters | ||||||
General | YZR5040JGK12QVehicle Model | YZR5040JGK12E | ||||
Vehicle Brand | XDR | |||||
Chassis Brand | Isuzu | |||||
Overall Dimension(mm) | 5998×2000×2960 | |||||
GVW/Curb Weight(kg) | 4495/4170 | |||||
Chassis Parameters | ||||||
Cab | Cab Seat | 2 | ||||
Air Conditioner | Optional | |||||
Engine | Fuel Type | diesel | ||||
Engine Model | 4KH1CN5LS | |||||
Engine Brand | isuzu | |||||
Power | 98hp | |||||
Displacement(cc) | 2999 | |||||
Emmission Standard | Euro5 | |||||
Chassis | Drive Type | 4*2 | ||||
Transmission | 5 speed, Manual | |||||
Wheelbase(mm) | 3360 | |||||
Tyre Specification | 7.00R16 | |||||
Tyre No.(pcs) | 6+1 | |||||
Max Speed(km/h) | 105 | |||||
Paint | Yellow | |||||
Aerial platform structure parameters | ||||||
working height(m) | 12 | Maximum working radius(m) | 6.2 | |||
Arm Material | carbon steel Q345 | Arm Thickness | ||||
Working height at Max.working radius(m) | 8.1 | Working radius at Max.working height(m) | 3 | |||
Outrigger distance(mm) | 3040*2890 | Platform average rise speed(m/s) | ≤0.4 | |||
Platform average fall speed(m/s) | ≤0.4 | Rotation speed (1r/min) | 1 | |||
Arm structure type | Three section | Outrigger stretch time (s) | 40 | |||
Rotation | 360°continuous rotary | Outrigger | H type,independently | |||
Remarks | ||||||
1. truck chassis brand is selectable 2.he outrigger operation box is equipped with a lighting device to facilitate work at night and configure the vehicle's bidirectional level to ensure the vehicle's level and ensure safety.3.The boom rotation is designed as a one-piece swivel to avoid assembly gaps during reassembly in production, and increases the space of the platform.4.Front and rear H-shaped legs, good stability, can be operated simultaneously or individually, standard washing boxes for all models 5.Upper arm limit device, when the upper arm exceeds the safety angle, the boom will be in a self-locking state to ensure the safety of the operator 6.Up and down steps are equipped on the side(aluminum alloy platform optional )7.The thickened cylinder seat and the boom cylinder block are all specially thickened to ensure the stability of the boom 8.Sectional coating to ensure the paint quality of the vehicle 9.All cutting parts are CNC laser cutting |
