HW-F1000-5 1000*1000MM Large Size Optical fresnel lens solar concentrator

Supplier: Shenzhen Haiwang Sensor Co., Ltd.
Region: Guangdong, China
Contact: Ms Cindy Wang
Price: $50.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

Packaging Detail:	Wooden Box;	size:	1000*1000mm;
Place of Origin:	Guangdong, China;	Payment Terms:	T/T,Western Union;
place of origin:	Shenzhen, China;	Shape:	PLANO;
groove pitch:	0.5mm;	Brand Name:	HW;
application:	solar cooker, solar system,cooking,heat water;	thickness:	5+-0.5mm;
Packing:	Wooden case;	material:	PMMA (arcylic);
Port:	Shenzhen;	Supply Ability:	10000 Pieces per Week;
Structure:	Plano-concave;	Model Number:	HW-F1000-5;
Type:	Spot lens;	Usage:	Optical;
focus:	1.3m;

1000*1000MM Large Size Optical fresnel lens solar concentrator

What is the specifications of our solar fresnel lens?

Size: 1000*1000mm

Thickness:5±0.5mm

Material: PMMA

Groove pitch: 0.5mm

Focus/Magnification: 1.3m

Transmission (%): 92 (from 400-1100nm)
Index of Refraction nd : 1.491
Operating Temperature (°C): 80 (Maximum)

What is the application of our solar fresnel lens?

1) focusing action
2) Widely used in solar hot water heating
3) Also be suitable for cooking food,Solar energy collector system, start a fire under sunlight, hot water heater, solar furnace, LCD projector etc.

What is the Feature and advantages of our solar fresnel lens?

1) High light transmittance
2) Hihh efficiency in focusing
2) We can provide customer fresnel lens,because we can make mould by ourselves
3) 10 years’ professional induction and design
4) High quality and competitive price
5) Good after-sales service
