Video external inspection: | if | Work efficiency: | 500 sqm/8 hours |
Voltage: | 220V/380V, 220V/380V | Applicable industries: | construction project |
Rotating speed: | 0-1800 rpm | application: | Concrete Surface Grinder |
Motor: | 7.5Kw | Number of discs: | 12 |
port: | Ningbo, Shanghai | Core Components Warranty: | 1 year |
strength: | 7.5Kw | Packaging Details: | Ground grinder concrete in wooden box, safe to transport |
weight: | 205 kg | Auto grade: | automatic |
usage: | Concrete Sander | Health status: | new |
Core components: | Gearbox, Motor | Supply capacity: | 100 pieces of ground grinder concrete per week |
Warranty: | 1 year | Marketing Type: | normal product |
Tank capacity: | 68L | Mechanical test report: | if |
place of origin; place of origin: | Shandong China | Dimensions (L*W*H): | 1100*700*1500mm |
Unique Selling Points: | High operating efficiency | Showroom location: | not any |
Packaging Preview: | Frequency Converter: | 7.5Kw | |
Working diameter: | 580mm | payment terms: | L/C,Western Union,T/T |
brand: | Seahawk |
Model | SHCG-500 | SHCG-600 | SHCG-640 | SHCG-700 |
Voltage | 220V/380V | 220V/380V | 220V/380V | 380V |
frequency converter | 7.5Kw | 7.5Kw | 7.5Kw/11Kw | 15Kw |
electricity | 7.5Kw | 7.5Kw | 7.5Kw | 15Kw |
working width | 490mm | 580mm | 630mm | 680mm |
Rotating speed | 1000-1800 rpm | 1000-1800 rpm | 1000-1800 rpm | 1200-2400 rpm |
number of discs | 12 | 12 | 12 | 12 |
water tank capacity | 60L | 60L | 60L | 80L |
weight | 215Kg | 235Kg | 260kg | 340kg |
Model | SHCG-520S | SHCG-620S | SHCG-650S | SHCG-680S | SHCG-720S |
Voltage | 220V/380V | 220V/380V | 380V | 380V | 380V |
frequency converter | 7.5KW/5.5KW | 7.5KW/11KW | 15kW | 15kW | 15Kw |
electricity | 7.5KW/5.5KW | 7.5KW | 11KW | 11KW | 18Kw |
working width | 520mm | 620mm | 650mm | 680mm | 720mm |
Rotating speed | 300-1800 rpm | 1000-1800 rpm | 1000-1800 rpm | 1400-1800 rpm | 1400-1800 rpm |
number of discs | 12 | 12 | 12 | 12 | 12 |
water tank capacity | 60L | 60L | 80L | 80L | 80L |
weight | 210Kg | 280kg | 340kg | 370Kg | 395 kg |
Model | SHCG-180 | SHCG-250D | SHCG-280 | SHCG-450 |
working diameter | 180mm | 250mm | 280mm | 450mm |
Voltage | 110v/220v/380v | 110v/220v/380v | 220v/380v | 220v/380v |
stage | 1 phase/3 phase | 1 phase/3 phase | 1 phase/3 phase | 1 phase/3 phase |
strength | 1.5KW (2.0hp) | 2.2KW (3.0hp) | 2.2KW (3.0hp) | 3 kW (4 hp) |
number of discs | 1 | 3 | 3 | 6 |
Rotating speed | 1410 rpm | 1410 rpm | 600 rpm | 550 rpm |
weight | 40kg | 65kg | 80kg | 110kg |
aspect | 680*220*600mm | 500*410*410mm | 900*520*900mm | 900*520*850mm |
