mcpcb 94v-0 pcb copper metal core direct thermal path pcb board pcba manufacturer for led light

  • Supplier: Mankun Electronic Co., Ltd.
  • Region: Guangdong, China
  • Contact: Ms Belinda hu
  • Price: $1.20 / 1 - 499 pieces
    $1.15 / >=500 pieces
  • Min. Order: 1 piece
Product details
Thermal Conductivity:1.0W/m°kFloor:single layer
Plate thickness:1.6mmproduct name:Mankiw
circuit board:custom led pcbother service:One-stop PCB Assembly Service
Certificate:CE ROHS ISO9001Solder Mask Color:white black yellow green red
model:CL09846Sales unit:single product
Packaging Preview:Single package size:4X4X0.16 cm
Packaging Details:Vacuum + bubble wrapbrand:Mankiw
Keyword 2:pcb boardplace of origin; place of origin:Guangdong, China
Substrate:aluminumminute. Line width:5000000
minute. Line spacing:5000000Silkscreen Color:black and white, other
Minimum order quantity:1 itemGross weight per piece:0.030 kg
Copper Thickness:35 micronsSurface treatment:operating system
minute. Aperture:0.3mm
Specification
product information
factory code
CL09847
thickness
1.6mm
Material
copper
surface treatment
operating system
copper thickness
35 microns
board color
white
application
light
Product Description
LED lighting series
Application: LED Lighting

1.
High thermal conductivity of copper substrate

2.
Raw materials and final PCB are fully UL compliant

3.
Applicable Products:
Street lights, tunnel lights, advertising lights, high bay lights, spotlights and other outdoor lighting.

4. Ability to customize PCB and assemble.
Model
PCB LED Module
LED light source
SMD 3030/3535
watts of LED board
3-40W
Input voltage
DC
application
production capacity
Metal substrate (MCPCB) technical parameters and process capabilities
thing
Specification
surface
LF HASL, Immersion Gold, Immersion Silver, OSP
Floor
Single-sided, double-sided multilayer and special structure
Maximum PCB size
LF HASL, Immersion Gold, Immersion Silver, OSP
PCB thickness
0.4-3.0mm
Copper foil thickness
H 1/2/3/4 (oz)
Insulation layer thickness
50/75/100/125/150/175/200(um)
Metal base thickness
Aluminum aluminum (1100/3003/5052/6061), copper aluminum aluminum
Metal base thickness
0.5/0.8/1.0/1.2/1.6/2.0/3.2/5.0(mm)
forming
Punching/CNC Route/V-Cut
test
100% open and short test
Forming tolerance
Die<+- 0.05mm, CNC Route<+-0.15mm, V-CUT Thickness Allowance>+-0.15mm
hole tolerance
+-0.5mm
Minimum aperture
Single-sided 0.5/double-sided PTH0.3MM
Solder mask
green/white/black/red/yellow
Minimum letter height
0.8mm
Minimum line spacing
0.15
Minimum letter width
0.15
screen color
blue/white/black/red/yellow
special hole
Spot Spot/Cup Hole/Buried Hole/Buried Can
file format
Gerber, Protel, PowerPCB, AutoCAD, etc.
