Beverage Factory Hot Sale Price Detachable Flange Plate Heat Exchanger

Supplier: Zhangjiagang Rachel Machine Co., Ltd.
Region: Jiangsu, China
Contact: Ms tokey xia
Price: $4000.00 / 1 - 1 sets
$3800.00 / 2 - 2 sets
$3200.00 / 3 - 3 sets
$3000.00 / >=4 sets
Min. Order: 1 set

Click here to contact

Product details

Processing:	heat exchanger	place of origin; place of origin:	Jiangsu, China
Supply capacity:	20 sets per month	License plate number:	107
diameter:	900470600mm	Key words:	Plate Heat Exchanger
Core components:	gear pump	pressure:	1 MPa
Health status:	new	Name:	Hot sale good price removable flange plate heat exchanger
Warranty:	1 year	range of working temperature:	-20~230℃, depending on gasket material
weight:	100kg	model:	RM-100S-170D
Mechanical test report:	if	Packaging Preview:
port:	Shanghai Port	Plate material:	SUS304
brand:	Rachel	Marketing Type:	normal product
Video external inspection:	if	Gasket Material:	EPDM rubber
Core Components Warranty:	1 year	Main selling point:	high productivity
Processing Type:	juice	Applicable industries:	Hotels, Clothing Stores, Building Materials Stores, Mechanical Repair Stores, Manufacturing Plants, Food and Beverage Plants, Farms, Restaurants, Home Use, Retail, Food Stores, Printing Stores, Construction Works, Energy and Mining, Food and Beverage Stores, Advertising Agencies
payment terms:	L/C,D/P,D/A,T/T,MoneyGram	Dimensions (LWH):	900470600mm
strength:	by order	Packaging Details:	Unpacked or according to each customer's request. Neutral packing, export standard carton packing or wooden box with packing film.
Showroom location:	Morocco, Kenya, Argentina, South Korea, Chile, United Arab Emirates, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzstan, Nigeria, Uzbekistan, Tajikistan, Japan, Malaysia, Australia	Test pressure:	1.25Mpa
Voltage:	220V-380V 50/60HZ

Function list

Plate Heat Exchanger

Plate heat exchangers are ideal equipment for heat exchange between liquid and steam. The advantage of this utility model is that
High heat exchange efficiency, small heat loss, compact and lightweight structure, small footprint, wide application range and long service life
life, etc. Under the same pressure loss, the heat transfer coefficient is 3-5 times higher than that of the tubular heat exchanger,
The floor area is only one third of that of the tubular heat exchanger, and the heat recovery rate can be as high as 90%.

right façade

left facade

Front view

Product Specifications

Plate Heat Exchanger
Material	Contact product parts	SS304,SS316L,SS316
Material		Contactless Product Components	SS304
Sealing material	standard	NBR or EPDM, silicone
pressure	work pressure	0~6bar
temperature	Operating temperature	-10~+150°C
temperature		Sterilization temperature	150℃≤30min
connect	UNION, flange
switch type	heating or cooling
One plate heat exchanger zone	0.02m2,0.04m2,0.06m2,0.08m2,0.15m2,0.24m2,0.65m2,0.85m2,1.54m2,1.8m2
plate thickness	0.7-1.0mm
flow	0-1000T
Specification	1 square meter - 60 square meters
