15.6'' Multi-touch Premium Nano Touch Film

Supplier: Shenzhen Wivitouch Technology Co., Ltd.
Region: Guangdong, China
Contact: Ms Selina WiViTouch
Price: $53.50 / 1 - 49 pieces
$45.50 / >=50 pieces
Min. Order: 1 piece

Click here to contact

Product details

Warranty Period (Years):	1 year	aspect ratio:	16:9
product status:	new	Contact point:	20 points can be upgraded to 40 points
brand:	wireless touch	place of origin; place of origin:	Guangdong, China
Scanning speed:	8 ms/frame	Warranty:	1 year
thickness:	≤200um	operating system:	Win7/8/8.1/10, Android, Linux
product name:	15.6'' Multi-touch Premium Nano Touch Film	After-sale service:	Call center and online technical support, on-site training and inspection, free spare parts, returns, repairs
Interface Type:	USB	custom made:	Yes
Touch sensor:	TX28 RX48	series:	business use
port:	Shenzhen	Packaging Details:	Cylinder: Includes 1pc Touch Foil, 1pc Touch Foil Controller, 1pc Touch Foil USB Cable
type:	Capacitive	Supply capacity:	3000 pieces per month
size:	15.6 inches (15-32 inches)	pack:	Yes
Certification:	Federal Communications Commission	color:	many

Product Description

What is WiViTouch Touch Film?

WiVi uses a unique transparent touch film that can be controlled through glass.

Everything is installed in the interior of the shop window.The WiVi Touch Foil can be combined with projection or LCD screens to create interactive store windows, outdoor/indoor kiosks, digital signage, touch screen tables, LCD displays and more.

The WiVi Touch Foil is like an eye-catcher, it creates instant interactivity.

parameter name	WiViTouch XT Series Capacitive Touch Film Specifications
Product Series	WVT-XTM	WVT-XTA	WVT-XTB	WVT-XTC
Contact point	12 points	20 points (Can be upgraded to 40 points)	30 points (Can be upgraded to 40 points)	40 marks
Regular size	15-43 inches	30-65 inches	55-98 inches	43-180 inches
touch bias	≤0.5mm	≤0.5mm	≤0.5mm	≤0.5mm
touch sensor	TX28 RX48	TX56 RX96	TX80 RX142	TX136 RX240
soft board	130	120	120
Scan speed	8 ms/frame				8 ms/frame	8 ms/frame	8 ms/frame
driver	Free drive
Windows	Win7/8/8.1/10
android	Kernel version 3.10+ or higher
Linux	Kernel version liunx3.10+ or higher
custom made	support
waterproof	Yes
Bias calibration	software calibration
Certificate	CE, ilac-MRA, CNAS, CAL, CMA, FCC, ROHS, ISO
packing list	Touch film1, controller1, 1.5m USB cable*1
thickness	≤200um
transparency	more than 93%
voltage	5V
transfer method	USB2.0
safe distance	2-5mm (distance between LED and touch film)
Transmission distance	≤50m (plus USB signal amplifier, etc.)
Gesture support	Click, drag, zoom, rotate
ambient light	Full point of anti-glare
Sensing distance	≤10mm

Why is touch film more and more popular?

1. Lightweight aluminum foil, easy to apply to windows, glass, acrylic and rear projection screens. 2. No need for any external wires or equipment as all touch screen components are safely behind the glass. 3. High quality transparent multi-touch foil (up to 40 touch points), multi-touch function - glass thickness up to 12mm. 4. Works with all existing multimedia applications PowerPoint, Macromedia Flash, websites, etc.

5. Insensitive to external light, light changes are not affected. 6. Wide selection of screen regular sizes, up to 100" 4:3 or 16:9 format. 7. Includes complete mounting kit - touch membrane, controller board and USB cable. 8. No mechanical or pressure sensitive components, Durable and stable. 9. Easy to install software.

10. Accurate positioning. 11. High resolution controller.

>>>Back to Category

>>> Contact us now

caution:

WVT-XTM-xxB for tail out from bottom;

The WVT-XTM-xxS is used to pull the tail from the short side.

What application is the touch film suitable for?

Integrated nano touch film can realize interactive projection system, touch all-in-one machine, touch coffee table/table, touch wall, touch TV, etc. These system integration products or solutions can be applied to exhibition/hotel/airport/government/home/teaching/shop window display/indoor/outdoor kiosk glass partition/company office/training/meeting room/exhibition/conference museum/tourist attraction

How does the touch film work?

Only a few microns thick, our thin-film displays can turn any surface into a high-definition multimedia display surface. Rear projected images, videos and dynamic media content can be displayed anywhere and in any format. Mounting method: Stick on glass, LCD or other media

Type A

Touch film + rear projection film + projector + computer

This type of installation solution can be used for glazing, shop window displays, indoor and outdoor kiosk glass partitions, training, meeting rooms

Type B

Touch film + LCD display + computer

This type of mounting solution can be used in touch kiosks, LCD displays, LCD advertising displays, ATMs, vending machines, etc.

>>>Back to Category

>>> Contact us now

Advantages of WiViTouch Touch Film

1. You bought it from the factory! Price, quality and delivery are guaranteed!

China's first R&D, production and sales touch film manufacturer, more than 10 years experience in touch film

FPC dual laser welding

Aluminum foil QC inspection

Control board QC inspection

workshop

stock

Quality inspection passed

2. Touch film certificate: CE, ilac-MRA, CNAS, CAL, CMA, FCC, ROHS, ISO

3. A strong R&D department, the world's leading touch film technology!

*The software is easy to operate and easy to maintain. Even a novice can complete the calibration in 1 minute.

* High signal-to-noise ratio makes it strong in anti-interference ability.

* Can work under glass up to 12mm (if the glass is thicker than 8mm, please let us know in advance).

* Support manual adjustment of threshold to adjust its sensitivity.

* FPGA algorithm realizes object recognition.

* If there is a cable damage, automatically amplify the signal of the adjacent cable, so as long as the damaged wire is separated from the other good wires, the foil will work fine.

* Touch without dead ends.

4. Professional equipment, customizable service.

*Accept customization: 10''-240'', format ratio (optional): 16:9, 16:10, 4:3, contact point: 12-40points

* The maximum size is 5850*1400mm.

* So far, the largest size we have made is 4100*1200mm.

5. Our team has more than 2-10 years sales experience, professional and efficient.

6.1 Years Comprehensive Free Warranty.

7. Fast delivery.

XTM series/dimensions	1 item	50 pieces	200 pieces	500 pieces and above
15.6 inches	5 working days	7 working days	8-10 working days	10-15 working days
17.1 inches	5 working days	7 working days	8-10 working days	10-15 working days
18.5 inches	5 working days	7 working days	8-10 working days	10-15 working days
19 inches	5 working days	7 working days	8-10 working days	10-15 working days
21.5 inches	5 working days	7 working days	8-10 working days	10-15 working days
22 inches	5 working days	7 working days	8-10 working days	10-15 working days
24 inches	5 working days	7 working days	8-10 working days	10-15 working days
27 inches	5 working days	7 working days	8-10 working days	10-15 working days
32 inches	5 working days	7 working days	8-10 working days	10-15 working days
43 inches	5 working days	7 working days	8-10 working days	10-15 working days
