Wheelbarrow factory: Wheelbarrow box production line.

Supplier: ATM DEUTSCHLAND MASCHINEN UND WERKZEUGE VERTRIEBS GMBH
Region: Saarland, Germany
Contact: Mr Halis Akinci
Price: $600780.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

place of origin; place of origin:	turkey	product name:	Hydraulic Press
After Warranty Service:	Online support, spare parts, on-site maintenance and repair services	application:	trolley
Marketing Type:	normal product	Local service location:	Turkey, Germany
Showroom location:	turkey	Health status:	new
Video external inspection:	if	After-sales service provided:	Free spare parts, online support, on-site installation, commissioning and training
brand:	ATM-Elmali	payment terms:	letter of credit
Production capacity:	240/hour	Applicable industries:	manufacturing plant
Warranty:	1 year	Mechanical test report:	if
port:	EXW-Konya	Energy source:	380V 50Hz

Product Description

Applications

Trolley factory
We offer a variety of production equipment including buckets, main legs, clamps, leg connecting rods, bucket connecting rods, rims.
1. The trolley production plant includes:
1.1. Sheet cutting lines include:
1.2. Uncoiler,
1.3. Straightener,
1.4. Feeder,
1.5. Hydraulic presses and
1.6. Mechanical shears for recycling.
2. Line drawing includes:
2.1. Hydraulic deep drawing machine
2.3. Conveyors
2.4. 2x Robots
3. Chamfering and Bending Machine
4. Screw hole punch
5. Frame profile bending punching machine

main feature

1) The linear structure is simple and easy to install and maintain.

2) Pneumatic part, electrical part and operation part all adopt advanced world-renowned brand components.

3) Automatic, intelligent and pollution-free operation

detailed image

Mechanical Parts

Name: Long Cutting Line

Card:Festo

The original:Germany

SCL100, fully automatic sheet metal cutting manufactured in three different widths: 1050, 1250 or 1550 mm. To handle cut sheets, the SCL100 is equipped with a stacking and transport system for fully automatic continuous operation.

Standard equipment

Name:Uncoiler, straightening feeding device
Card:Servo Steel
The original:Germany/Turkey
Uncoiler, straightening and feeding device (feed speed 30 m/min, measurement accuracy +/- 0.3 mm/m)
Cutting unit - specially executed mechanical shears (cutting speed up to 60 cuts/min)
stacking system

Mechanical Parts

Name:500t deep drawing machine
Card:ATM
The original:Germany/Turkey
Domestic famous brand engine, strong power, low energy consumption, high economic benefits.

main feature

Name:Chamfering and Bending Machine
Card:el mary
The original:Germany/Turkey
Domestic famous brand engine, strong power, low energy consumption, high economic benefits
