Easy to install high efficiency 5kw horizontal wind turbine magnet price list windmill generator 5kw for sale

Supplier: Qingdao Greef New Energy Equipment Co., Ltd.
Region: Shandong, China
Contact: Ms Christina Lei
Price: $499.00 /set
Min. Order: 1 set

Click here to contact

Product details

model:	AH-5W	rated power:	5000W, 5kW
port:	Qingdao	Tower height:	8m Free Folding Tower
custom made:	Yes	Rated wind speed:	11m/s
Supply capacity:	2000 sets per month	Start wind speed:	2.5m/s
Top Weight:	400kg	place of origin; place of origin:	Shandong China
Packaging Details:	Home Wind Turbine Foam + Plywood Shell	Safe wind speed:	50 m/s
Blade material and quantity:	FRP/3PCS	Working wind speed:	3-30m/s
brand:	Gree F	Blade rotor diameter:	5.6M
Certification:	Chief Executive	payment terms:	Western Union, T/T, MoneyGram, PAYPAL
Operating temperature:	-20℃~+50℃	Packaging Preview:
Warranty:	3 years

Why choose AH-5KW fan?

Leading technology - intelligent control, strong system scalability

1. The world's best wind power control technology is combined with the independently developed pitch technology.
2. The hardware design adopts international famous brands, and the software adopts redundant control strategy.
3. It can achieve good compatibility with various well-known brand converters and remote modules.

High security - continuous operation 24/7 for unattended operation
1. The speed of the wind wheel is controllable, and it can run continuously and stably under strong wind conditions.
2. More than ten redundant control strategies to ensure the safety and stability of the system under various climatic conditions.

Large amount of power generation - pitch control, high-efficiency output, power generation up to 30%
1. Above the rated wind speed, the pitch angle of the blades can be adjusted to achieve continuous full power output.
2. The working wind speed range is large (3-25m/s), and the effective running time is long.

Recommended for:

· Home, Garden, Farm, City, Roof
· Telecom sites.
· Rural electrification program. island, sentry, island, sight lighting
· Automatic deceleration protection

Technical Specifications

Model	AH-5KW
Rotor diameter (m)	5.6
Blade material and quantity	FRP*3
Rated power (kW)	5
Rated wind speed (m/s)	11
Rated speed (r/min)	240
Generator type	Three-phase PMG
Working wind speed (m/s)	3-30
Start wind speed (m/s)	2.5
Survival wind speed (m/s)	60
Rated Voltage(VDC)	400/240/custom
Speed mode	pitch control
wind answer	windward
stop method	automatic braking
Gale Protection	Intelligent control + unattended
Weight (kg)	400
Noise level (dB)	≤65
Tower height (m)	≥8
tower type	leaning tower
Operating temperature	-20℃～+50℃
