Warranty: | 10 years | place of origin; place of origin: | Jiangsu, China |
Diameter of wind wheel: | 1.1m | model: | SC-800 |
rated power: | 800w | Rated wind speed: | 13m/s |
The output voltage: | 800w | dynamo: | Three-phase permanent magnet synchronous generator |
custom made: | Yes | rated power: | 24v |
brand: | FLTXNY | payment terms: | L/C,Western Union,T/T,MoneyGram |
Survival wind speed: | 40 m/s | Packaging Details: | export wooden box |
Packaging Preview: | | Certification: | Chief Executive |
Service life: | more than 20 years | Start wind speed: | 1.3m/s |
Blade length: | 580 | Rated voltage: | 12V/24V |
Maximum power: | 850w | | |
1. Low starting speed, 5 blades, high wind energy utilization rate 2. Easy installation, optional pipe or flange connection 3. Blades
Using a new precision injection molding process, with optimized aerodynamic shape and structure, to improve wind energy
Utilization rate and annual production. 4. Cast aluminum alloy body with 2 bearings to rotate, making it able to withstand stronger wind and running
5. The patented permanent magnet alternator is equipped with a special stator, which can effectively reduce the torque and match the wind wheel.
generator and guarantee the performance of the entire system. 6. The controller and inverter can be selected according to customer requirements (optional)
specific needs
Des/model: SC-1000-5B Rated power (W): 1000W Maximum power (W): 1050w Rated voltage (AC): 12v/24V/48v Wheel diameter: 1.2m Starting wind speed|(m/s): 1.3 m /s Rated wind speed|(m/s): 13m/s Survival wind speed|(m/s): 50m/s Number of blades (m): 5 Blade length: 550mm
The price defaults to 24v
Advantages of Off-Grid Solar Systems
1.Unable to access utility grid
Off-grid solar systems may be cheaper than extending power lines in some remote areas.
If you are more than 100 yards from the grid, consider going off-grid. Overhead transmission lines cost anywhere from $174,000 per mile (rural construction) to $11,000,000 per mile (urban construction).
2.become energy self-sufficient
It feels good to live off the grid and be self-sufficient. For some, that feeling is more valuable than saving money.
Energy self-sufficiency is also a form of security. Power failures on the utility grid will not affect off-grid wind power systems.
On the other hand, batteries can only store a certain amount of energy, and on cloudy days, connecting to the grid is actually a safe place. You should install backup generators to prepare for these situations.
Model | SC-800 | SC-1000 |
Rated power (w) | 800w | 1000W |
Maximum power (w) | 850w | 1500W |
Rated voltage (v) | 12/24v | 12/24V |
Blade length (mm) | 580 | 580 |
Top net weight (kg) | 10 | 10 |
Diameter of wind wheel (m) | 1.1 | 1.1 |
Rated wind speed (m/s) | 13m/s | 13m/s |
Start wind speed | 1.3/s | 1.3/s |
Survival wind speed | 40 m/s | 40 m/s |
dynamo | 13-phase permanent magnet synchronous generator | 13-phase permanent magnet synchronous generator |
service life | more than 20 years | more than 20 years |
bearing | HRB or for your order | HRB or for your order |
Blade material | nylon | nylon |
Shell material | Aluminum alloy | Aluminum alloy |
Permanent magnet material | Rare Earth NdFeB | Rare Earth NdFeB |
Control System | electromagnet | electromagnet |
lubricating | grease | grease |
Operating temperature | -40 to 80 | -40 to 80 |
Manufacturer street light home 1kw 24v wind turbine 800w vertical turbine air turbine
Shipping methods and fees are not the best for all countries, please contact us to see the best shipping method to your address and we will try to offer you the greatest discount.
1. Competitive price--We are a factory/manufacturer, so we can control the production cost and then sell at the lowest price.
2. Quality controllable
--All products will be produced in our factory, so we can show you every detail of production and let you check the quality of your order.
3. Multiple payment methods
-- We accept online Alipay, bank transfer, Paypal, LC, Western Union, etc.
4. Various forms of cooperation
--We not only provide you with our products, if needed, we can be your partner and design products according to your requirements. Our factory is your factory!
5. Perfect after-sales service
--As a manufacturer of wind turbine and generator products for more than 4 years, we are very experienced in dealing with various issues. So no matter what happens, we will solve it as soon as possible.
