Y241 steel packer oil well drilling oil packer oil packer

Supplier: Dongying Oilman Machinery Equipment Co., Ltd.
Region: Shandong, China
Contact: Mr Oilman Zhang
Price: $2000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Work pressure:	20Mpa-75Mpa	Core components:	Packer
product name:	Y241 steel packer oil well drilling packer oil tool packer	Advantage:	high performance
Marketing Type:	normal product	port:	Tianjin harbor
Local service location:	not any	Video shipment inspection:	if
usage:	oil, gas, water	Mechanical test report:	if
brand:	oil man	Applicable industries:	Energy and Mining
Showroom location:	not any	Supply capacity:	500 sets of Y241 steel packer oil well drilling packer oil tool packer per month
Warranty:	1.5 years	payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram
type:	Completion tool	Packaging Details:	Y241 steel baler oil well drilling baler oil tool baler export plywood box
After warranty service:	Video technical support, online support	model:	K344,Y344,Y341,Y241,Y211...
Health status:	new	Core component warranty:	1 year

Y241 steel packer oil well drilling packer oil tool packer

Product Description

Y241 steel packer oil well drilling packer oil tool packer

1. Application

Oil well drilling packers are mainly used in various constructions such as layered oil production, water injection, water exploration, plugging, squeezing, acidizing, and fracturing.

Cup packing machine

Mechanical baler

hydraulic packer

2. Principle

Sealing: When going downhole, the control pin is on the short track. When the packer is in the desired position, the mast is pulled to loading height, then the mast is lowered so that the control pin is tangent to the long track. The slips extend and block the inner wall of the pipe. The barrel is compressed to achieve a seal.

Unsealing: Pull up the cylinder to reset the slips to realize unsealing.

3. Technical parameters

type	Applicable tube mm	total length mm	Maximum outer diameter mm	Minimum ID mm	work pressure MPa	set load KN	backwash cubic meter/hour	centralizer outer diameter mm	Operating temperature Celsius
Y211-114	121-124	2080	114	48 years old	35	100~140	/	114-133	120
Y211-136	143-150	2080	136	60	35	100~140	/	136-157	120
Y211-148	154-164	2080	148	60	35	100~140	/	148-168	120

4. Structure:

As shown in the figure above, the Y211 packer is composed of a high-temperature, high-pressure anti-corrosion cylinder, the entire center pipe, a friction commutator and a lower joint. Slips are carburized and quenched. The surface stiffness and core toughness are very high, and it is not easy to break when it conflicts with the load. The barrel is located above the slide to avoid being covered with sand. The structure is simple and the operation is convenient.
