High Rigidity CT5 Double Spindle CNC Lathe CNC Lathe

  • Supplier: DALIAN DRC MACHINERY CO., LTD.
  • Region: Liaoning, China
  • Contact: Ms DRC MACHINERY
  • Price: $71500.00 / 1 - 4 sets
    $68500.00 / >=5 sets
  • Min. Order: 1 set
Product details
Maximum cutting length:500 mmChuck diameter:210mm
Voltage:220/380Health status:new
Maximum cutting diameter:390mmSpindle bore diameter (mm):74
Travel (X axis) (mm):180 mmTravel (Z axis) (mm):525mm
CNC system:FANUCBed width (mm):500mm
Video shipment inspection:ifpayment terms:L/C, Western Union, T/T
Main selling points:high security levelMaximum swing in bed:576mm
Front bearing diameter:100mmSpindle motor power (kW):15
Applicable industries:Manufacturing plants, construction, energy and miningWeight (kg):4000
maximum. Moment:112 NmRepeatability (X/Y/Z) (mm):0.002
place of origin; place of origin:Liaoning, ChinaNumber of spindles:twin
CNC turning center:Double spindle CNC lathe Cnc Turning Centertype:Turning Center
maximum. Work piece length (mm):550Positioning accuracy (mm):0.005
Packaging Details:Custom Eyelash Packaging High Rigidity CT5 Dual Spindle CNC Lathe CNC Turning CenterShowroom location:Turkey, UK, Italy, France, Germany, Vietnam, Indonesia, Pakistan, Mexico, Russia, Thailand, Morocco, Kenya, South Korea, UAE, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Kazakhstan, Ukraine, Kyrgyzstan , Nigeria, Uzbekistan, Tajikistan, Japan, Malaysia
Speed ​​range:5-5000 rpmCore component warranty:1 year
model:CT5Warranty:1 year
Core components:Motors, pumps, gearsyear:2022
Spindle power:11-15kwbrand:Democratic Republic of the Congo
Processing capacity:burdenSupply capacity:Monthly production of 500 high-rigidity CT5 double-spindle CNC lathes
Mechanical test report:ifmaximum. Spindle speed (rpm):5000 rpm
port:DalianTool Station:12
Marketing Type:New Products 2020Number of axes:5
Dimensions (L*W*H):2750/1700/1850 mmSpindle maximum speed:5000 rpm
High Rigidity CT5 Double Spindle CNC Lathe CNC Lathe
Product Description
FANUC Inclined Bed Turn-Mill Compound Center Four-Axis Turning Center Machine Description:CNC lathe is a four-axis linkage, fully closed-loop CNC machine tool. The mechanical, electro-hydraulic integration layout adopts a fully enclosed protective cover, the door opens to the left, and the operating console is located at the right end of the fixed protective cover. The ergonomic swing design makes the operation more convenient. Each servo feed axis adopts a high-speed silent ball screw, directly connected by an elastic coupling, with fast moving speed, low noise, high positioning accuracy and high repeat positioning accuracy; the servo motor is equipped with an absolute value encoder, no cumulative error, no Memory, no need to find the reference point, and the position information will not be lost after power off. The machine tool has strong functions, high precision, reasonable layout, beautiful appearance, simple operation and convenient maintenance.
Fanuc CNC Turn-Mill Compound Center 4-Axis Turning CenterDistributor HT5MY/ Industry: Fludics/ Material: 16MnCr5/ Dimensions: 32x150mm/ Complete Machined Connector with Drive Tool / HT5MY/ Industry: Mechanical / Material: Ck45/ Dimensions: 80x20mm/ Complete Machined Reduction Socket with Drive Tool / HT5MY/ Industry: Hydraulics / Material: Ck45 / Dimensions: 70x80mm / Chatter-free surfaces cycled using "alternating speed" technologyemphasize:1. The HT300 high tension Meehanite cast iron bed has a compact design. 2. Perfect accessibility and optimum working depth. 3. Ideal training machine with minimal space occupation and suitable spindle working depth. 4. Up to 16 driving tools (optional) increase productivity. 5. The latest CNC control technology: FANUC OiTF+ with Manual Guide i (as a standard package) or SIEMENS 828D with Shopturn function (as a standard package), and prepare a large number of customized interfaces.
Specification
technical date
Spindle head
type
FL 140 h5/A2-6
Spindle speed
Rotating speed
5000
maximum. torque
N×m
112
Spindle power
kilowatt
11-15
Chuck diameter
mm
210
Spindle hole
mm
74
Front bearing diameter
mm
100
Spindle bearing lubrication
type
grease
Linear Motion Lubrication
type
Oil
speed range
Rotating speed
5-5000
Work area
maximum swing in bed
mm
576
cutting diameter
mm
390
cutting length
mm
500
Maximum bar capacity
mm
51
Z-axis/X-axis/Y-axis travel
mm
525 /180 / ±35
Ball screw rod
X/Z axis ball screw DxP
mm
32x10/40x5/32x10
feed
Quickly move Z/X/C/Y
m/min
24/24/12/100
Feed force
Feed force X/Z
cow rice
4500
Number of axes
4
measuring system
X/Z axis measuring system
absolute rotation
(X / Z); VDI/DGQ 3441 positioning
mm
0.008/0.008/0.01
(X/ Z); VDI/DGQ 3441 repeatability
mm
0.005/0.005/0.008
Tailstock
Tailstock travel
mm
500
Tailstock movable
hydraulic programmable
maximum. Tailstock pressure
no
4000
Tailstock center sleeve
type
MT 4
Servo Turret
Number of pockets
-
12
Turntable type
-
Slot plate
Tool accessories
mm
25/40
Electrical Specifications
Voltage
V
380±10%
frequency
hertz
50±1%
maximum. Installed power
kVA
20
400v lie protection fuse
One
63
400v line automatic circuit breaker
One
33
connection cable section
square millimeter
4×10
hydraulic device
maximum. work pressure
bar
40
reservoir capacity
Lift
35
pump flow
Count me in
twenty four
cooling system
Tank capacity
Lift
180
pump delivery
l/min
30
pump pressure
bar
5
noise level
less than
decibel(A)
≤80
Control System
FANUC
-
FANUC 0iTF + MGi
net weight
Kilogram
about 4000
angle of inclination, material
-
45°, HT300
