Diamond Cutting Polishing Machine Alloy Wheel Restoration CNC Lathe

Supplier: Yancheng Yujie Machine Co., Ltd.
Region: Jiangsu, China
Contact: Ms nunu zhu
Price: $13500.00 / 1 - 4 sets
$13000.00 / 5 - 9 sets
$12500.00 / >=10 sets
Min. Order: 1 set

Click here to contact

Product details

Number of axes:	2	After-sales service provided:	Engineers available to repair machinery overseas, online support, video technical support, free spare parts
Positioning accuracy (mm):	±0.01	Bed width (mm):	360 mm
Packaging Details:	wooden box	Repeatability (X/Y/Z) (mm):	±0.01
Mechanical test report:	if	Weight (kg):	2300
Spindle bore diameter (mm):	52	Spindle motor power (kW):	5.5
Tool Station:	4	type:	horizontal
Video outbound inspection:	if	Automatic level:	automatic
maximum. Workpiece weight (kg):	100	brand:	Yujie
maximum. Spindle speed (rev/min):	750 rpm	Supply capacity:	20 sets per month
payment terms:	L/C, Western Union, T/T	maximum. Work piece length (mm):	750
Year:	2021	Applicable industries:	Other, auto repair shop
weight:	1800 kg	Local service locations:	Türkiye, UK, US, Germany
Processing capacity:	medium	Certification:	ISO9001:2008
Travel (Z axis) (mm):	500mm	strength:	5.5 kW
Voltage:	380V/3P/50HZ or as your request	Travel (X-axis) (mm):	365mm
Health status:	new	Package preview:
maximum. Swing diameter:	660mm	Whether CNC:	CNC system
structure:	Flat bed lathe	Origin:	Jiangsu, China
Core components:	Bearings, motors, pumps, gears, PLCs, motors, controllers	Warranty:	1 year
port:	Shanghai	maximum. Turning length (mm):	550
Marketing Type:	2020 New Products	Core component warranty:	1 year
Main selling points:	easy to operate	Number of spindles:	single
Showroom location:	Türkiye, UK, US, Germany, Australia	After Warranty Service:	Video technical support, online support, spare parts
model:	AWR26	Dimensions (LWH):	205015001850mm

Product Description

Magnetic repair machine 14-26 inches

Features

Features are as follows

Specification

The parameters are as follows

Specification
thing		unit	AWR23	AWR26	AWR28	AWR32
production capacity	maximum. bed swing diameter	mm	600(23")	660(26")	720(28")	820 (32")
	maximum. Gap rotation diameter	mm	700	Chapter 760	820	960
	maximum. alloy wheel size	mm	600 (twenty three")	660 (26")	712(28")	813 (32")
	maximum Turning length	mm	650		1000
	Rail width	mm	360		400
travel	axis travel	mm	X: 350; Z: 500		X: 450; Z: 930
Spindle	Spindle speed	rpm	40-1800		40-1800
	Spindle Taper	mt	6#		6#
	Spindle Hole	mm	52		80
turret	tool number	pieces	4		4
	handle size	mm	25×25		25×25
feed	quickly × axis movement	mm/min	3000		3000
	quickly Z axis movement	mm/min	6000		6000
	to cut feed	mm/rev	0.005-100		0.005-100
engine	main Motor Power	kilowatt	5.5		7.5
	X and Z axis motor		servo engine		servo engine
others	comprehensive Dimensions (length x width x height)	mm	2100x1600x1850	2100x1700x1950	2450x1850x2200		2450x1900x2250
	weight	Kilogram	1850	2300	3200		3500
according to			separate part cast iron base	all part cast iron base
