Zhenjiang factory zinc brass gold-plated nickel-plated twisted RG11 RF coaxial connector

Product details
MOQ:1000Supply capacity:1,000,000 pieces per month
Package preview:Frequency Range:0~1GHz
place of origin; place of origin:Jiangsu, ChinaPack:100pcs/pack
Certificate two:CTIKey words:RG11 F connector
temperature range:-55℃~+165model:Zhenjiang F108
brand:new high frequencydescribe:F connector
Material:brasspayment terms:Western Union, T/T
port:Shanghai/NingboTypes of:RF adapter
impedance:75ΩPackaging Details:100PCS/bag, 1000PCS/carton
Durability:500 (cycle)plating:nickel plated
Product Description



F RF connectorIs the cheapest general-purpose connector with a non-constant impedance, suitable for voltages of 500 volts or less, and frequencies down to 500Mhz. F-type coaxial connectors are widely used in cable TV, MATV, CCTV and related consumer TV products.



temperature range: -40~+60℃ Insulation resistance: ≥ 1000 MΩ
impedance: 75Ω Sea level pressure resistance: 750V
Frequency Range: 0~1GHz Operating Voltage: 170V max
Center conductor pullout force: ≥0.49N VSWR: Straight line≤1.2 Angle≤1.3
Contact resistance: Center conductor≤6mΩ, outer conductor≤1mΩ Durability: 500 cycles

F-connectorLimited options are available to accommodate various cable sizes.

technical characteristics
temperature. Range……………-40~+60℃
Impedance................................75Ω
Frequency range...................DC~1GHz
Operating Voltage.............170V max
Withstanding voltage……………500V rms

Contact resistance
Center contact......≤10mΩ
External contact......≤5mmΩ
Insulation resistance...≥1000 mΩ
Standing wave ratio......≤1.20
Right angle?................≤1.30
Durability (mating)..........500 (cycles)



Materials and Plating
Housing.............Brass....Nickel Plated
Contact Pins.....Brass.....Gold Plated
Resilient Contacts...Beryllium...Gold or Silver Plated
Insulator.........PTFE or PE
Crimp Kit.....Copper Alloy....Nickel Plated
