Protection class: | IP65 or higher | Origin: | Henan, China |
exhibit: | LCD digital display | Medium temperature: | -20℃~+120℃ |
Warranty: | 18 months | pressure: | 1.6Mpa/2.5Mpa/4.0Mpa/6.3Mpa/10Mpa/16Mpa/25Mpa, |
connect: | Flange/Clamp/Thread/Insert | Moderate: | Oil/Fuel/Diesel Oil/Edible Oil/Vegetable Oil/Lubricating Oil |
Single package size: | 35X19X23 cm | Packaging Details: | Each of our flowmeters has been factory-calibrated and packed according to different sizes. Usually, flowmeters below 100mm are packed in beautiful cartons, and flowmeters above 100mm are packed in steam-free boxes. We will ensure that every flow meter reaches your hands safely |
Gross weight per piece: | 35.500 kg | Signal output: | 4-20mA/pulse |
Explosion-proof grade: | ExiallCT4/ExiallBT6 | Sales unit: | single product |
Customization support: | OEM, ODM, OBM, software reengineering | type: | Oil/Fuel/Diesel Flow Meter, Liquid Flow Meter, Edible Oil/Vegetable Oil Flow Meter, Turbine Flow Meter |
power supply: | 24VDC/220VAC/3.0V battery | Package preview: | |
model: | Lu Wengui | Communication output: | RS485/Modbus/HART protocol |
brand: | tail |
Product advantages high precision Strong anti-interference ability Simple structure easy installation maintain good repeatability |
Executive standard: | Turbine flowmeter sensor (JB/T9246~19999) |
Caliber & Connection: | Thread connection: DN4, 6, 10, 15, 20, 25, 32, 40; Flange connection: DN (15, 20, 25, 32, 40) 50, 65, 80, 100, 125, 150, 200; Clamp connection: DN4, 6, 10, 15, 20, 25, 32, 40, 50, 65, 80 |
accuracy: | ±0.1%, ±0.5%, ±0.2% (optional) |
Turndown ratio: | 1:10;1:15;1:20 |
Sensor material: | SS304 stainless steel, SS316(L) stainless steel, etc. |
working environment: | Medium temperature: -20℃~+120℃ Ambient temperature: -20℃~+20℃ Relative humidity: 5%~90% Atmospheric pressure: 86KPA~106KPA |
Signal output: | Pulse, 4~20ma |
Communication output: | RS485, Hart |
Working power supply: | A: DC 24V lithium battery |
Signal line interface: | Basic type, explosion-proof type |
Explosion-proof grade: | ExiaΙΙCT4 or ExdΙΙBT6 |
Protection class: | IP65 or higher |
