Outer diameter: | 8~42mm | Origin: | Sichuan, China |
Grain Size: | 0.8~1.2 microns | Screw tooth size: | M4~M16 |
port: | Chongqing, Shanghai, Ningbo, Guangzhou, Shenzhen, Hong Kong, Fujian, etc. | TRS: | 2400~3000 N/mm² |
hardness: | HRA70~80 | Packaging Details: | Wooden case/carton/iron case and other plastic bags or boxes. |
Supply capacity: | 5000 pieces per month | density: | 13.95~14.5g/cubic centimeter |
brand: | Ding Li | length: | 15~43mm |
Material: | steel, steel | Package preview: | |
type: | SDUCR/STUCR/SCLCR etc. | payment terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,Visa |
grade: | 45#/65# |
- Carbide grades:
grade | ISO code | chemical composition (%) | Granularity um | physical and mechanical properties (≥) | ||||
bathroom | limited company | others | Density g/cm3 | Hardness (HRA) | TRS Newton/mm2 | |||
D10UF | K05-K15 | 93 | 6 | 1 | 0.6 | 14.70 | 93.0 | 2600 |
D30UF | K20-K30 | 89 | 10 | 1 | 0.6 | 14.50 | 92.0 | 3800 |
D30SF | K20-K30 | 89 | 10 | 1 | 0.5 | 14.40 | 92.5 | 4000 |
D40SF | K40 | 87 | 12 | 1 | 0.4 | 14.30 | 92.5 | 4200 |
DB10X | K20-K30 | 89 | 10 | 1 | 0.6 | 14.50 | 91.5 | 3800 |
DP12X | K30-K40 | 87 | 12 | 1 | 0.6 | 14.15 | 91.0 | 3300 |
DP13X | K40 | 86 | 13 | 1 | 0.8 | 14.10 | 90.5 | 4400 |
YG6 | K05-K10 | 93 | 6 | 0 | 1.2 | 14.95 | 91.0 | 2600 |
YG6X | K10 | 93 | 6 | 0 | 1.0 | 14.95 | 92.0 | 2500 |
YG8 | K20-K30 | 92 | 8 | 0 | 1.2 | 14.70 | 90.0 | 2800 |
YG10X | K30-K40 | 89 | 10 | 1 | 0.8 | 14.50 | 91.0 | 3500 |
YG15 | K40 | 85 | 15 | 0 | 1.2 | 14:00 | 87.5 | 4500 |
YG25 | -- | 75 | 25 | 0 | 1.2 | 13.15 | 82.5 | 4800 |
Zigong Dingli Alloy Co., Ltd. is located in the new industrial parkZigong, Sichuan, China's famous cemented carbide production base. thisfactoryMainly engaged in the production and development of various cemented carbide products, such asRod tubes, anti-vibration shaft tubes and flat bars.In China, our goal is to become a manufacturing center base for extruded bars, carbide boring bars, standard tools, non-standard tools and hard machining tools, and to establish a good and healthy corporate image in the industry.
The main production equipment:
Currently the company can. In general, our products can be used in the manufacture of moulds, electronic products, automobile engines and accessories, military equipment, petroleum machinery, machinery manufacturing, etc. We have stable clients such asUSA, Russia, Indonesia, Korea, Japan, Australiaetc.
Testing Machine:
Our company was established in July 2011. The quality and reputation of the company's products have reached the upper-middle level in China, second only to several most competitive cemented carbide companies. We continuously improve technology and introduce advanced equipment, which has greatly improved the professionalism and production scale.
Production flow chart:
Package
1>Put the goods packed in plastic bags or plastic boxes into wooden boxes/cartons/iron boxes, etc.
2>Other packing will be accepted according to your needs.
FAQ
Q1: How long is your lead time?
A1: It depends on the specific situation. However, it may take 10 to 15 days on average.
Q2: Do you provide samples?
A2: Yes, we do provide samples. However, buyers need to pay for shipping. Also, whether the samples are free or not depends on the quantity you buy.
Q3: How do you pack the products?
A3: Generally, we use wood, plastic or carton. We also put some soft material inside to prevent possible damage to the product.
Q4: How much advance payment do I need to pay?
A4: If the product you purchased is in stock, you need to pay in full; if the product is out of stock, you need to pay about 50% of the full payment, and then we will start the production process. However, you still need to pay the remaining cost before we deliver the product.
Q5: What kind of payment methods do you accept?
A5: In addition to the payment methods shown above, you can also discuss with us which payment method you would like to adopt.
