RVM1100 Halogen Moisture Analyzer Laboratory Moisture Detector

RVM1100 Halogen Moisture Analyzer

1.Introduction:

The halogen rapid moisture analyzer is a new type of rapid moisture detection instrument. Its ring-shaped halogen heater ensures that the sample is evenly heated during the high temperature test process, so that the surface of the sample is not easily damaged, and it dries quickly. During the drying process, the moisture analyzer continues. The moisture content% of the sample lost is measured and displayed immediately. After the drying process is completed, the final moisture content value is locked and displayed. Compared with the international oven heating method, the test results have good consistency, are replaceable, and the detection efficiency is much higher than the oven method. Generally, the sample can be measured in just 4-5 minutes. The instrument is simple to operate and accurate to test. The display part adopts a large-screen display screen. The displayed values are clearly visible, and can display data such as moisture value, sample initial value, final value, measurement time, initial temperature value, and final temperature value. It has the function of connecting with computer and printer. The moisture meter is widely used in all industries that require rapid determination of moisture, such as medicine, food, feed, seeds, dehydrated vegetables, tobacco, chemicals, tea, food, meat, agriculture, forestry, paper, rubber, plastic, textile and other industries. Test and data printing of moisture content in intermediate, intermediate and finished samples.

2.Features:

     ★ Weighing section adopts high-precision and high-quality sensors to fully guarantee stable weighing without drifting;

     ★ Precision shell, heating some imported polymer materials, ultra-high temperature molding to ensure product performance;

     ★ Ring halogen lamp heating, multi-layer stainless steel heating chamber, heating up quickly during testing, uniform heating, effectively improving heating efficiency and shortening working time;

     ★ Large LCD screen display, with multi-button operation, easy operation and clear test results. At the same time, a printer can be optionally selected to objectively record the test results for easy reference;

     ★ RS232 data interface can realize PC and printer connection, and can store data inside.

3.Parameters:

Model: RVM1100

Range: 124g

Weighing readability: 0.0001g

Moisture readability : 0.001%

Moisture accuracy: ≤0.5%（ Sample weight ≥2g）

Temperature control tolerance: 0.1℃

Heating temperature range: 40 ° C to 200 ° C (adjusted at 1 ° C)

Heating time range: 0-99 minutes (in 1 minute) adjustment

Endpoint control: Timing automatic manual

Results display parameters: 8 types (see section 3.5 for details)

Heating source: Halogen lamp

Measuring moisture range: 0%～100%

Sample tray size: 90mm

Communication: Serial RS232

physical dimension: 350*220*205mm

Net weight: 5.8KG
