mini Zoomlion 90 m3/h concrete batching plant germany HZS90P specification

Product details
Packaging Detail:nude;Supply Ability:150 Unit/Units per Month;
Theoretical producting periods (s):60;Brand Name:Zoomlion;
Place of Origin:Hunan China (Mainland);Discharge height (m):4;
Power(W):130kw;Mixer:JS1500;
Payment Terms:L/C,D/A,D/P,T/T,Western Union,MoneyGram;Dimension(L*W*H):12920mm*13000mm*17300mm;
Aggregate storage (m3):3*13;Condition:New;
Weight:40T;After-sales Service Provided:Video technical support,Field installation, commissioning and training,Field maintenance and repair service,Free spare parts,Online support;
Applicable Industries:Hotels,Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Construction works ;Port:Shanghai Port;
Warranty:1 Year;After-sales Service Provided:Engineers available to service machinery overseas;
Certification:CE ISO;

mini Zoomlion 90 m3/h concrete batching plant germany HZS90P specification





Product Description



This mixer is perfect for concrete construction thanks to its excellent mixing performance, accurate and stable measuring, high dependability and its high degree of modularity. It is also easy to maintain and simple to transport.It can be used for various construction projects, for example, roads, railways, ports, bridges and airports etc., as well as in commercial concrete production.
ModelHZS90P
Theoretical rated output (m³/h)90
Discharge height (m)4
MixerJS1500
Theoretical producting periods (s)60
Aggregate storage (m³)3×16
Max. weighing value of slant belt conveyor (kg)190
The conveying capacity of screw conveyor (t/h)40
Total power (kW)130
Batching range and accuracy of aggregate (kg)(0-2400)±2%
Batching range and accuracy of cement (kg)(0-800)±1%
Batching range and accuracy of Admixtures (kg)(0-400)±1%
Batching range and accuracy of water (kg)(0-350)±1%
Batching range and accuracy of additive (liquid) (kg)(0-20)±1%
