High output second hand tires pyrolysis to oil plant

Supplier: Xinxiang City Jinzhen Machinery Manufacturing Co., Ltd.
Region: Henan, China
Contact: Ms. Alan Zhang
Price: $40000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Raw material:	waste rubber,plastic and tire;	Place of Origin:	Henan China;
Final product:	oil,gas,carbon black;	Supply Ability:	20 Set/Sets per Month second hand tyre pyrolysis plant;
Condition:	New;	After-sales Service Provided:	Field installation, commissioning and training;
After-sales Service Provided:	Engineers available to service machinery overseas;	Condensing method:	Water circulation;
Port:	Qingdao/ Tianjin/ Shanghai Port;	Warranty:	2 Years;
Equipment Capacity:	1-20Tons/day;	Key Selling Points:	High Productivity;
Automatic Grade:	Automatic;	Power(W):	14KW/17KW;
Voltage:	220V/380V or customized;	Brand Name:	JINZHEN second hand tyre pyrolysis plant;
Working form:	Continuous;	Name:	High output second hand tires pyrolysis to oil plant;
Warranty:	1 year;	Certification:	CE,ISO,SGS,UL;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	Applicable Industries:	Hotels,Restaurant;
Packaging Detail:	JZ-22006000 240HQ JZ-22006600 240HQ JZ-24006000 140HQ AND 140 FR JZ-24006600 140HQ AND 140 FR JZ-28006000 140HQ AND 140 FR JZ-28006600 140HQ AND 140 FR Tyre Recycling!! automatic tyre recycling machine from best factory;

Waste plastic used tyre pyrolysis to fuel oil machine used oil pyrolysiis oil refinery plant.

Product Description

The technology and equipment which use waste rubber, plastic catalysted with normalpressure, pyrolysis fuel oil developed by our company, the refining of gasoline, diesel fuel can be detected up to standards by the quality supervision bureau, complementingthe growing failure of the oil resources from the fundamental, turning waste into treasure, improving the ecological environment, and also to create greater economic and social benefits.

Parameters of rubber tyre plastic pyrolysis machine:

equipment’s model	JZ-05	JZ-08	JZ-10	JZ-12	JZ-15
Raw material	Waste rubbers/tyres/plastic	Waste rubbers/tyres/plastic	Waste rubbers/tyres/plastic	Waste rubbers/tyres/plastic	Waste rubbers/tyres/plastic
Daily Handling capacity	5 tons	8 tons	10 tons	12 tons	15 tons
Working pressure	Normal pressure	Normal pressure	Normal pressure	Normal pressure	Normal pressure
Main engine rotating speed	0.4R /min	0.4R /min	0.4R /min	0.4R /min	0.4R /min
Equipped power	3KW	3KW	3KW	3KW	3KW
Cooling Mode	Water	Water	Water	Water	Water
Floor Area	150m2	160m2	180m2	200m2	200m2
Heating Mode	Direct	Direct	Direct	Direct	Direct
Oil Yield	45%-50%	45%-50%	45%-50%	45%-50%	45%-50%
Noise dB (A)	<=85	<=85	<=85	<=85	<=85
Machine dimension(mm)	D2200*L5000	D2200*L6600	D2600*L6600	D2800*L6600	D2800*L6600
Working Mode	Intermittence	Intermittence	Intermittence	Intermittence	Intermittence

1.Fuel oil(40-50%)

The main oil product produced by our recycling application is the fuel oil that is wide used for industrial and commercial purposes.

2.Steel wire(10-15%)

Tyres contain steel wires and the amount ranges from 10%-15% of the total tyre weight.All of the steel present in the tyre can be detached after the pyrolysis recycling process is completed.Valuable steel wires are presses and sold to steel and scrap dealers.

3.Carbon black(30-35%)

Carbon black is the main product recycled by pyrolysis techonlogy.The amount of recycled carbon black is 34-42%.Carbon black is used as raw material or main ingredient in many industries and the chemical structure of carbon black strengthens,lengthens the endurance,and improves the coloring features of the materials.

4.Gas

Non-condesable gases arise during the recycling application which has a higher calorific value compared to natural gas;can replace natural gas and propane when stored;can be used as energy resource in gas burners,also used in pyrolysis system.The amount of gas generated in the system is 12-15% of the total amount of recycled tyres and considering the 10ton scrap tyre/day recycling capacity,the facility generates 1400-1500m3/day gas which has an enormous energy potential when evaluated.

<<< Get Categories & Factory Price Now >>>

Company Information

Xinxiang Cty Jinzhen Machinery Manufacturing Co., Ltd is a private enterprise with more than 10 years of development in HENAN. At present, the company has product research, manufacturing, market trinity comprehensive strength. The main products cover all over the world. The company has always been adhering to the “high-tech, high starting point, high quality, high speed’ as the general policy of science and technology is popular the factory. The enterprise overall through ISO9001:2008, CE, BV, etc.

My company is located in the central plains transportation center - Xinxiang, covers an area of 100 mu(96000 square meter), with one modern laboratory, large-scale production workshop and other production of experimental base. Have more than 100 management personnel, sales personnel and technical personnel.

High quality products and warm service warmly welcome your arrival!

Client from the world wide for the waste tyre plastic rubber pyrolysis:

<<< Get Categories & Factory Price Now >>>

Packaging & Shipping

Delivery time

We will delivery the machine within 15-25days after get the advance payment.

Port (China)

lianyungang port & qingdao port & shanghai port

Warranty and machine life

We guarantee the complete machine 2 years, the reactor life more than 4 years,others

parts no need change lifelong expect the wearing parts.

Our Services

1. Quality warranty period: Jinzhen’s plants enjoy one-year guarantee, after which, we still offer lifelong technical support for your plant.

2. Our After-sales Service Department will pay you regular visits for any feedback, opinions or suggestions.

3. For any tiny plant problem you cannot solve after one-year guarantee finishes, please feel free to Email or call our salespeople, who will wholeheartedly help you solve your problem.

4. For problems that cannot be solved via email or phone-call, our engineers may be dispatched to do plant maintenance and debugging (which usually takes as short as one day) until your plant resumes normal operation.

5. For the damage caused by the users, our company provides the parts and accessories with cost price.
